Analog and Interface Product Selector Guide
5
THERMAL MANAGEMENT: Multichannel Temperature Sensors
Part #
Typical
Accuracy
(°C)
Maximum
Accuracy
@ 25°C (°C)
Maximum
Temperature
Range (°C)
Vcc Range
(V)
Maximum
Supply
Current (µA)
Features Packages
Serial Output Temperature Sensors (Continued)
AT30TSE754A ±0.5 ±1 −55 to +125 +1.7 to +5.5 125
SMBus/I
2
C compatible interface, nonvoltatile registers to retain user-congured or pre-dened power-up defaults,
integrated 4 KB serial EEPROM
8-pin SOIC, 8-pin MSOP,
8-pin 2 × 3 UDFN
AT30TSE758A ±0.5 ±1 −55 to +125 +1.7 to +5.5 125
SMBus/I
2
C compatible interface, nonvoltatile registers to retain user-congured or pre-dened power-up defaults,
integrated 8 KB serial EEPROM
8-pin SOIC, 8-pin MSOP,
8-pin 2 × 3 UDFN
AT30TSE002B ±1 ±3 −40 to +125 +2.7 to +3.6 500 JEDEC (JC42.4) SO-DIMM SPD + TS compliant, SMBus/I
2
C compatible interface, integrated 2 KB serial EEPROM 8-pin 2 × 3 UDFN
AT30TSE004A ±0.5 ±3 −40 to +125 +1.7 to +3.6 500 JEDEC JC42.4 (TSE2004av) DIMM SPD + TS compliant, SMBus/I
2
C compatible interface, integrated 4 KB serial EEPROM 8-pin 2 × 3 UDFN
THERMAL MANAGEMENT PRODUCTS: Multichannel Temperature Sensors
Part #
# of Remote
Temp.
Sensors
Typ.
Accuracy
(°C)
Maximum
Accuracy
@ 25°C (°C)
Maximum
Temp. Range
(°C)
Ambient
Temp.
Sensor
Alert/
THERM
Hardware
Shutdown
Vcc
Range
(V)
Typ.Supply
Current
(µA)
Description and Additional Features Packages
Serial Output Temperature Sensors with Multichannel Temperature Sensors
MIC184 1 ±1.0 ±2.0 −55 to +125 1 1 – 2.7–5.5 340 Local/Remote Thermal Supervisor 8-pin SOIC, 8-pin MSOP
MIC280 1 ±1.0 ±2.0 −55 to +125 1 1 – 3.0–3.6 230 Precision IttyBitty
®
Thermal Supervisor 6-pin SOT
MIC281 1 ±1.0 ±3.0 −55 to +125 0 1 – 3.0–3.6 230 Low-Cost IttyBitty Thermal Sensor 6-pin SOT
MIC284 1 ±1.0 ±2.0 −55 to +125 1 2 – 2.7–5.5 350 Two-Zone Thermal Supervisor with CRIT Output 8-pin SOIC, 8-pin MSOP
MIC384 2 ±1.0 ±2.0 −55 to +125 1 1 – 2.7–5.5 350 Three-Zone Thermal Supervisor 8-pin SOIC, 8-pin MSOP
MCP9902 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperature Dual Temperature Sensor 8-pin WDFN
MCP9903 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperature Triple Temperature Sensor 10-pin 3 × 3 VDFN
MCP9904 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperature Quad Temperature Sensor 10-pin 3 × 3 VDFN
EMC1046 5 ±0.25 ±1.0 −40 to +125 1 – – 3.0–3.6 395 Sextuple SMBus/I
2
C Sensor with REC, Beta Compensation and Hottest of Thermal Zones 10-pin MSOP
EMC1047 6 ±0.25 ±1.0 −40 to +125 1 – – 3.0–3.6 395 Septuple SMBus/I
2
C Sensor with REC, Beta Compensation and Hottest of Thermal Zones 10-pin MSOP
EMC1072 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Dual SMBus/I
2
C Sensor with Selectable Address 8-pin MSOP
EMC1073 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Triple SMBus/I
2
C Sensor with Selectable Address 10-pin MSOP
EMC1074 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Quad SMBus/I
2
C Sensor with Selectable Address 10-pin MSOP
EMC1812 1 ±0.25 ±1.0 −40 to +125 1 2 – 1.62–3.6 25
Dual Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
8-pin WDFN
EMC1813 2 ±0.25 ±1.0 −40 to +125 1 2 – 1.62–3.6 25
Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
10-pin VDFN
EMC1814 3 ±0.25 ±1.0 −40 to +125 1 2 – 1.62–3.6 25
Quad Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
10-pin VDFN
EMC1815 4 ±0.25 ±1.0 −40 to +125 1 2 – 1.62–3.6 25
Five Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction,
Beta Comp
10-pin VDFN
EMC1833 2 ±0.25 ±1.0 −40 to +125 1 2 – 1.62–3.6 25
Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
8-pin WDFN
EMC1412 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Dual SMBus/I
2
C Sensor with REC, Beta Compensation and Selectable Address 8-pin TDFN, 8-pin MSOP
EMC1413 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Triple SMBus/I
2
C Sensor with REC, Beta Compensation and Selectable Address 10-pin DFN, 10-pin MSOP
EMC1414 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Quad SMBus/I
2
C Sensor with REC, Beta Compensation and Selectable Address 10-pin MSOP, 10-pin DFN
EMC1422 1 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Dual SMBus/I
2
C Sensor with REC, Beta Compensation and Resistor-Settable Hardware
Thermal Shutdown
8-pin MSOP
EMC1423 2 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Triple SMBus/I
2
C Sensor with REC, Beta Compensation and Resistor-Settable Hardware
Thermal Shutdown
10-pin MSOP
EMC1424 3 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Quad SMBus/I
2
C Sensor with REC, Beta Compensation and Resistor-Settable Hardware
Thermal Shutdown
10-pin MSOP
EMC1428 7 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 450
Octal SMBus/I
2
C Sensor REC, Beta Compensation and Resistor-Settable Hardware
Thermal Shutdown and Hottest of Thermal Zones
16-pin QFN
EMC1438 7 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 450
Octal SMBus/I
2
C Sensor REC, Beta Compensation and Resistor-Settable Hardware
Thermal Shutdown and Hottest of Thermal Zones
16-pin QFN
EMC1822 1 ±0.25 ±1.0 −40 to +125 1 1 1 1.62–3.6 25
Dual Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
8 WDFN
EMC1823 2 ±0.25 ±1.0 −40 to +125 1 1 1 1.62–3.6 25
Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
10 VDFN
EMC1824 3 ±0.25 ±1.0 −40 to +125 1 1 1 1.62–3.6 25
Quad Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
10 VDFN
EMC1825 4 ±0.25 ±1.0 −40 to +125 1 1 1 1.62–3.6 25
Five Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
10 VDFN
EMC1843 2 ±0.25 ±1.0 −40 to +125 1 1 1 1.62–3.6 25
Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error
Correction, Beta Comp
8 WDFN
Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor. 2: Maximum accuracy measured at 85°C. 3: TCN75 idle current is 250 mA. This device also has a Software Shutdown mode that
reduces supply current to < 1 mA.
