Analog and Interface Product Selector Guide
THERMAL MANAGEMENT PRODUCTS: Temperature Sensors (Continued)
Part #
# of Remote
Temp.
Sensors
Typical
Accuracy
(°C)
Maximum
Accuracy
@ 25°C (°C)
Maximum
Temperature
Range (°C)
Ambient
Temp.
Sensor
Alert/
THERM
Hardware
Shutdown
Vcc Range
(V)
Typical
Supply
Current (µA)
Description and Additional Features Packages
Serial Output Temperature Sensors with Remote Diode Monitors
MIC184 1 ±1.0 ±2.0 −55 to +125 1 1 – 2.7–5.5 340 Local/Remote Thermal Supervisor 8-pin SOIC, 8-pin MSOP
MIC280 1 ±1.0 ±2.0 −55 to +125 1 1 – 3.0–3.6 230 Precision IttyBitty® Thermal Supervisor 6-pin SOT
MIC281 1 ±1.0 ±3.0 −55 to +125 0 1 – 3.0–3.6 230 Low-Cost IttyBitty Thermal Sensor 6-pin SOT
MIC284 1 ±1.0 ±2.0 −55 to +125 1 2 – 2.7–5.5 350 Two-Zone Thermal Supervisor with CRIT Output 8-pin SOIC, 8-pin MSOP
MIC384 2 ±1.0 ±2.0 −55 to +125 1 1 – 2.7–5.5 350 Three-Zone Thermal Supervisor 8-pin SOIC, 8-pin MSOP
MCP9902 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperature Dual Temperature Sensor 8-pin WDFN
MCP9903 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperature Triple Temperature Sensor 10-pin 3 × 3 VDFN
MCP9904 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 450 Lower Temperpature Quad Temperature Sensor 10-pin 3 × 3 VDFN
EMC1033 2 ±1.0 ±3 −40 to +125 1 2 – 3.0–3.6 50 Triple SMBus/I
2
C Sensor with Resistance Error Correction 8-pin MSOP
EMC1043 2 ±0.5 ±1.0 −40 to +125 1 – – 3.0–3.6 105
Triple SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Hotter of Two Zones
8-pin MSOP
EMC1046 5 ±0.25 ±1.0 −40 to +125 1 – – 3.0–3.6 395
Sextuple SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Hottest of Thermal Zones
10-pin MSOP
EMC1047 6 ±0.25 ±1.0 −40 to +125 1 – – 3.0–3.6 395
Septuple SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Hottest of Thermal Zones
10-pin MSOP
EMC1053 2 ±0.5 ±1.0 −40 to +125 1 – – 3.0–3.6 105
Triple SMBus/I
2
C Sensor with Resistance Error Correction and Hotter of
Two Zones
8-pin MSOP
EMC1063 2 ±0.5 ±1.0 −40 to +125 1 – 3.0–3.6 105 Triple SMBus/I
2
C Sensor with Hotter of Two Zones 8-pin MSOP
EMC1072 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Dual SMBus/I
2
C Sensor with Selectable Address 8-pin MSOP
EMC1073 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Triple SMBus/I
2
C Sensor with Selectable Address 10-pin MSOP
EMC1074 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430 Quad SMBus/I
2
C Sensor with Selectable Address 10-pin MSOP
EMC1182 1 ±0.25 ±1.0 −40 to +125 1 2 - 3.0–3.6 200
Dual Channel 1.8V SMBus/I
2
C Temperature Sensor with Resistance
Error Correction, Beta Compensation
8-pin TDFN,
8-pin DFN
EMC1183 2 ±0.25 ±1.0 −40 to +125 1 2 - 3.0–3.6 200
Triple Channel 1.8V SMBus/I
2
C Temperature Sensor with Resistance
Error Correction, Beta Compensation
10-pin DFN
EMC1184 3 ±0.25 ±1.0 −40 to +125 1 2 - 3.0–3.6 200
Quad Channel 1.8V SMBus/I
2
C Temperature Sensor with Resistance
Error Correction, Beta Compensation
10-pin DFN
EMC1186 1 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 200
Dual Channel 1.8V SMBus/I
2
C Sensor with Resisitance Error Correction,
Beta Compensation and Resistor-Settable Hardware Thermal Shutdown
8-pin TDFN
EMC1187 2 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 200
Triple Channel 1.8V SMBus/I
2
C Sensor with Resisitance Error Correction,
Beta Compensation and Resistor-Settable Hardware Thermal Shutdown
10-pin DFN
EMC1188 3 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 200
Quad Channel 1.8V SMBus/I
2
C Sensor with Resisitance Error Correction,
Beta Compensation and Resistor-Settable Hardware Thermal Shutdown
10-pin DFN
EMC1412 1 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430
Dual SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Selectable Address
8-pin TDFN,
8-pin MSOP
EMC1413 2 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430
Triple SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Selectable Address
10-pin DFN,
10-pin MSOP
EMC1414 3 ±0.25 ±1.0 −40 to +125 1 2 – 3.0–3.6 430
Quad SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Selectable Address
10-pin MSOP,
10-pin DFN
EMC1422 1 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Dual SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Resistor-Settable Hardware Thermal Shutdown
8-pin MSOP
EMC1423 2 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Triple SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Resistor-Settable Hardware Thermal Shutdown
10-pin MSOP
EMC1424 3 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 430
Quad SMBus/I
2
C Sensor with Resisitance Error Correction, Beta
Compensation and Resistor-Settable Hardware Thermal Shutdown
10-pin MSOP
EMC1428 7 ±0.25 ±1.0 −40 to +125 1 1 1 3.0–3.6 450
Octal SMBus/I
2
C Sensor Resisitance Error Correction, Beta
Compensation and Resistor-Settable Hardware Thermal Shutdown and
Hottest of Thermal Zones
16-pin QFN
Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.
2: Maximum accuracy measured at 85°C.
3: TCN75 idle current is 250 mA. This device also has a Software Shutdown mode that reduces supply current to <1 mA.
