Navigating the Catalog
(continued on next page )
RFI Power Line Filters
Solutions associated with EMI/RFI susceptibility as well as compliance to interna-
tional emissions standards for single phase power applications. Includes chassis
and board mountable designs as well as single and two-stage filters.
Three Phase Filters
Solutions associated with EMI/RFI susceptibility as well as compliance to interna-
tional emissions standards for three phase and high current applications.
IEC Inlet and Power Entry Modules
IEC inlet power filters and modular products that address a variety of power entry
needs by combining several functions such as on/off switching, voltage selection
switching, fuseholder, filtering in co
mbination with the IEC inlet connector.
DC Power Line Filters
EMI/RFI solutions for emissions and susceptibility specifically related to DC
systems often found in central office and telecommunication applications.
Feedthrough Filters and Capacitors
Products designed for through-bulkhead mounting for high frequency filtering.
Designed to meet EN133200 and EN132400 safety requirements. Available in a
variety of st
andard as well as custom configurations.
Signal Line Products
Products that combine different levels of filtering with various sized RJ modular
jacks. Signal line products are used to protect data transmissions as they pass
through the RJ jacks or as they are transmitted on the PCB.
Step 1: Determine the product family.
The Corcom product guide contains seven sections with six distinct product families. Use the index
numbers along the side of the catalog to quickly jump to that section.
7
Technical Notes
The appendices in the back of the catalog offer information such as safety
agency classifications, general information regarding RFI, and testing procedures.
Corcom Product Families
Looking for Corcom EMI Facility Products?
Power, data and signal line filters for shielded installations
Available in Catalog 1654986 - see page 8 for more information
