Overview
www.ti.com
1.2 Related Documentation from Texas Instruments
The following document provides information regarding Texas Instruments' integrated circuits used in the
assembly of the TMP107EVM. This user's guide is available from the TI web site under literature number
SBOU158. Any letter appended to the literature number corresponds to the document revision that is
current at the time of the writing of this document. The latest revision can be found by clicking the link in
Table 2 and is also available from the TI web site, the Texas Instruments' Literature Response Center at
(800) 477-8924, and the Product Information Center at (972) 644-5580. When ordering, identify the
document by both title and literature number.
Table 2. Related Documentation
Document Literature Number
TMP107 product data sheet SBOS716
2 Quick-Start Setup and Use
Follow these steps to set up and use the TMP107EVM:
1. Download and install the Virtual Com Port drivers from www.ftdichip.com/Drivers/VCP.htm.
2. Download and install the TMP107EVM graphical user interface (GUI) software from
www.ti.com/tool/TMP107EVM.
3. If not already connected, attach the three-conductor cable to J2; see Figure 4.
4. Insert J1 into an open USB port on the computer with the software and drivers installed.
5. Select the Com Port from the Serial Port drop-down box associated with the TMP107EVM and click
the Initialize System button. When the Number of Devices field shows the appropriate number of
devices in the daisy chain (4, if the default hardware included in the TMP107EVM kit is used) and the
lower right field of the status bar reads CONNECTED in green, select the Global Device tab from the
Pages sidebar.
6. Push the Global Run Continuous button to start capturing the temperature of all TMP107 devices in
the daisy-chain and to display those measurements in the Temperature Array ºC field and in the Global
Temperature Plots waveform chart.
4
TMP107EVM User's Guide SBOU158–August 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
