TMS320C6745, TMS320C6747
www.ti.com
SPRS377F –SEPTEMBER 2008–REVISED JUNE 2014
The peripheral set includes: a 10/100 Mbps Ethernet MAC (EMAC) with a management data input/output
(MDIO) module; two I
2
C Bus interfaces; 3 multichannel audio serial ports (McASPs) with 16/9 serializers
and FIFO buffers; two 64-bit general-purpose timers each configurable (one configurable as watchdog); a
configurable 16-bit host-port interface (HPI) [TMS320C6747 only]; up to 8 banks of 16 pins of general-
purpose input/output (GPIO) with programmable interrupt/event generation modes, multiplexed with other
peripherals; 3 UART interfaces (one with both RTS and CTS); three enhanced high-resolution pulse width
modulator (eHRPWM) peripherals; three 32-bit enhanced capture (eCAP) module peripherals which can
be configured as 3 capture inputs or 3 auxiliary pulse width modulator (APWM) outputs; two 32-bit
enhanced quadrature encoded pulse (eQEP) peripherals; and 2 external memory interfaces: an
asynchronous and SDRAM external memory interface (EMIFA) for slower memories or peripherals, and a
higher speed memory interface (EMIFB) for SDRAM.
The Ethernet Media Access Controller (EMAC) provides an efficient interface between the
TMS320C6745/6747 device and the network. The EMAC supports both 10Base-T and 100Base-TX, or 10
Mbps and 100 Mbps in either half- or full-duplex mode. Additionally, an MDIO interface is available for
PHY configuration.
The rich peripheral set provides the ability to control external peripheral devices and communicate with
external processors. For details on each of the peripherals, see the related sections later in this document
and the associated peripheral reference guides.
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE
TMS320C6745 HLQFP (176) 24.00 mm x 24.00 mm
TMS320C6747 BGA (256) 17.00 mm x 17.00 mm
(1) For more information on these devices, see Section 8, Mechanical Packaging and Orderable
Information.
Copyright © 2008–2014, Texas Instruments Incorporated TMS320C6745, TMS320C6747 Fixed- and Floating-Point Digital Signal 3
Processor
Submit Documentation Feedback
Product Folder Links: TMS320C6745 TMS320C6747
