Copyright © 2008–2016, Texas Instruments IncorporatedDevice Comparison
Submit Documentation Feedback
Product Folder Links: TMS320F28027 TMS320F28026 TMS320F28023 TMS320F28022 TMS320F28021
TMS320F28020 TMS320F280200
6
TMS320F28027
,
TMS320F28026
,
TMS320F28023
,
TMS320F28022
TMS320F28021
,
TMS320F28020
,
TMS320F280200
SPRS523K –NOVEMBER 2008–REVISED JUNE 2016
www.ti.com
(1) A type change represents a major functional feature difference in a peripheral module. Within a peripheral type, there may be minor differences between devices that do not affect the
basic functionality of the module. These device-specific differences are listed in the C2000 Real-Time Control Peripherals Reference Guide and in the peripheral reference guides.
(2) TMS320F28027F and TMS320F28026F are InstaSPIN-FOC-enabled MCUs. For more information, see Section 8.4 for a list of InstaSPIN Technical Reference Manuals.
3 Device Comparison
Table 3-1 lists the features of the TMS320F2802x devices.
Table 3-1. Device Comparison
FEATURE TYPE
(1)
28027
28027F
(2)
(60 MHz)
28026
28026F
(2)
(60 MHz)
28023
(50 MHz)
28022
(50 MHz)
28021
(40 MHz)
28020
(40 MHz)
280200
(40 MHz)
Package Type
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
38-Pin DA
TSSOP
48-Pin PT
LQFP
Instruction cycle – 16.67 ns 16.67 ns 20 ns 20 ns 25 ns 25 ns 25 ns
On-chip flash (16-bit word) – 32K 16K 32K 16K 32K 16K 8K
On-chip SARAM (16-bit word) – 6K 6K 6K 6K 5K 3K 3K
Code security for on-chip
flash/SARAM/OTP blocks
– Yes Yes Yes Yes Yes Yes Yes
Boot ROM (8K x 16) – Yes Yes Yes Yes Yes Yes Yes
One-time programmable (OTP) ROM (16-
bit word)
– 1K 1K 1K 1K 1K 1K 1K
ePWM channels 1 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4) 8 (ePWM1/2/3/4)
eCAP inputs 0 1 1 1 1 1 1 –
Watchdog timer – Yes Yes Yes Yes Yes Yes Yes
12-Bit ADC
MSPS
3
4.6 4.6 3 3 2 2 2
Conversion Time 216.67 ns 216.67 ns 260 ns 260 ns 500 ns 500 ns 500 ns
Channels 7 13 7 13 7 13 7 13 7 13 7 13 7 13
Temperature Sensor Yes Yes Yes Yes Yes Yes Yes
Dual Sample-and-Hold Yes Yes Yes Yes Yes Yes Yes
32-Bit CPU timers – 3 3 3 3 3 3 3
High-resolution ePWM Channels 1 4 (ePWM1A/2A/3A/4A) 4 (ePWM1A/2A/3A/4A) 4 (ePWM1A/2A/3A/4A) 4 (ePWM1A/2A/3A/4A) – – –
Comparators w/ Integrated DACs 0 1 2 1 2 1 2 1 2 1 2 1 2 1 2
Inter-integrated circuit (I2C) 0 1 1 1 1 1 1 1
Serial Peripheral Interface (SPI) 1 1 1 1 1 1 1 1
Serial Communications Interface (SCI) 0 1 1 1 1 1 1 1
I/O pins (shared)
Digital (GPIO) – 20 22 20 22 20 22 20 22 20 22 20 22 20 22
Analog (AIO) – 6 6 6 6 6 6 6
External interrupts – 3 3 3 3 3 3 3
Supply voltage (nominal) – 3.3 V 3.3 V 3.3 V 3.3 V 3.3 V 3.3 V 3.3 V
