An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
TMS320F28379S
,
TMS320F28378S
,
TMS320F28377S
TMS320F28376S, TMS320F28375S, TMS320F28374S
SPRS881D –AUGUST 2014–REVISED JULY 2017
TMS320F2837xS Delfino™ Microcontrollers
1 Device Overview
1
1.1 Features
1
• TMS320C28x 32-Bit CPU
– 200 MHz
– IEEE 754 Single-Precision Floating-Point Unit
(FPU)
– Trigonometric Math Unit (TMU)
– Viterbi/Complex Math Unit (VCU-II)
• Programmable Control Law Accelerator (CLA)
– 200 MHz
– IEEE 754 Single-Precision Floating-Point
Instructions
– Executes Code Independently of Main CPU
• On-Chip Memory
– 512KB (256KW) or 1MB (512KW) of Flash
(ECC-Protected)
– 132KB (66KW) or 164KB (82KW) of RAM
(ECC-Protected or Parity-Protected)
– Dual-Zone Security Supporting Third-Party
Development
• Clock and System Control
– Two Internal Zero-Pin 10-MHz Oscillators
– On-Chip Crystal Oscillator
– Windowed Watchdog Timer Module
– Missing Clock Detection Circuitry
• 1.2-V Core, 3.3-V I/O Design
• System Peripherals
– Two External Memory Interfaces (EMIFs) With
ASRAM and SDRAM Support
– 6-Channel Direct Memory Access (DMA)
Controller
– Up to 169 Individually Programmable,
Multiplexed General-Purpose Input/Output
(GPIO) Pins With Input Filtering
– Expanded Peripheral Interrupt Controller (ePIE)
– Multiple Low-Power Mode (LPM) Support With
External Wakeup
• Communications Peripherals
– USB 2.0 (MAC + PHY)
– Support for 12-Pin 3.3 V-Compatible Universal
Parallel Port (uPP) Interface
– Two Controller Area Network (CAN) Modules
(Pin-Bootable)
– Three High-Speed (up to 50-MHz) SPI Ports
(Pin-Bootable)
– Two Multichannel Buffered Serial Ports
(McBSPs)
– Four Serial Communications Interfaces
(SCI/UART) (Pin-Bootable)
– Two I2C Interfaces (Pin-Bootable)
• Analog Subsystem
– Up to Four Analog-to-Digital Converters (ADCs)
– 16-Bit Mode
– 1.1 MSPS Each (up to 4.4-MSPS System
Throughput)
– Differential Inputs
– Up to 12 External Channels
– 12-Bit Mode
– 3.5 MSPS Each (up to 14-MSPS System
Throughput)
– Single-Ended Inputs
– Up to 24 External Channels
– Single Sample-and-Hold (S/H) on Each ADC
– Hardware-Integrated Post-Processing of ADC
Conversions
– Saturating Offset Calibration
– Error From Setpoint Calculation
– High, Low, and Zero-Crossing Compare,
With Interrupt Capability
– Trigger-to-Sample Delay Capture
– Eight Windowed Comparators With 12-Bit
Digital-to-Analog Converter (DAC) References
– Three 12-Bit Buffered DAC Outputs
• Enhanced Control Peripherals
– 24 PWM Channels With Enhanced Features
– 16 High-Resolution Pulse Width Modulator
(HRPWM) Channels
– High Resolution on Both A and B Channels of
8 PWM Modules
– Dead-Band Support (on Both Standard and
High Resolution)
– Six Enhanced Capture (eCAP) Modules
– Three Enhanced Quadrature Encoder Pulse
(eQEP) Modules
– Eight Sigma-Delta Filter Module (SDFM) Input
Channels, 2 Parallel Filters per Channel
– Standard SDFM Data Filtering
– Comparator Filter for Fast Action for Out of
Range
