User's Guide
SLVUAC7–December 2014
TPD6F002-Q1EVM
This user's guide describes the characteristics, operation, and use of the TPD6F002-Q1EVM evaluation
module (EVM). This EVM includes 2 TPD6F002-Q1’s for testing. One TPD6F002-Q1 is configured for
IEC61000-4-2 compliance testing and one TPD6F002-Q1 is configured for 4-port s-parameter analysis.
Additionally, the TPD6F002-Q1 for ESD testing allows the capture of a clamping waveform during an ESD
event. This user's guide includes setup instructions, schematic diagrams, a bill of materials, and printed-
circuit board layout drawings for the evaluation module.
1 Introduction
Texas Instrument’s TPD6F002-Q1 evaluation module helps designers evaluate the operation and
performance of the TPD6F002-Q1 device. The TPD6F002-Q1 is a six-channel EMI filter in a space-saving
DSV package. This low-pass filter array reduces EMI emissions and provides system-level ESD protection
at the data ports. Because of its small package and easy-to-use pin assignments, this device is suitable
for a wide array of applications such as mobile handsets, PDAs, video consoles, notebook computers, etc.
In particular, the TPD6F002 is ideal for EMI filtering and protecting data lines from ESD at the LCD
display, keypad, and memory interfaces. The pi-style (C-R-C) filter provides at least 35 dB attenuation in
the carrier frequency range. The TPD6F002 is a highly integrated device designed to suppress EMI/RFI
noise in all systems subjected to electromagnetic interferences. This filter includes ESD protection circuitry
that prevents damage to the application when subjected to ESD up to IEC 61000-4-2 ±20 kV Contact ESD
and ± 30 kV Air-Gap ESD. The TPD6F002-Q1 is characterized for operation over an ambient air
temperature range of –40°C to 125°C.
The EVM contains two TPD6F002-Q1’s. A TPD6F002-Q1 (U1) is configured with test points for striking
ESD to the protection pins. It also has an SMB (J5) connector for capturing clamping waveforms with an
oscilloscope during an ESD strike. Caution must be taken when capturing clamping waveforms during an
ESD event so as not to damage the oscilloscope. A proper procedure is outlined below in Oscilloscope
Setup. A TPD6F002-Q1 (U2) is configured with 4 SMA (J1 – J4) connectors to allow 4-port analysis with a
vector network analyzer.
Table 1. EVM Configuration
Reference Designator TI Part Number Configuration
IEC61000-4-2 ESD Tests and ESD Clamping
U1 TPD6F002-Q1
waveforms
U2 TPD6F002-Q1 S-parameters
2 Definitions
Contact Discharge — a method of testing in which the electrode of the ESD simulator is held in contact
with the device-under-test (DUT).
Air Discharge — a method of testing in which the charged electrode of the ESD simulator approaches
the DUT, and a spark to the DUT actuates the discharge.
ESD simulator — a device that outputs IEC61000-4-2 compliance ESD waveforms shown in Figure 1
with adjustable ranges shown in Table 2 and Table 3.
IEC61000-4-2 has 4 classes of protection levels. Classes 1 – 4 are shown in Table 2. Stress tests
should be incrementally tested to level 4 as shown in Table 3 until the point of failure. If the DUT
does not fail at 8 kV, testing can continue in 2 kV increments until failure.
1
SLVUAC7–December 2014 TPD6F002-Q1EVM
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
