Altera Corporation 1
FLEX 8000
Programmable Logic
Device Family
January 2003, ver. 11.1 Data Sheet
DS-F8000-11.1
FLEX 8000
3
1
Features...
■ Low-cost, high-density, register-rich CMOS programmable logic
device (PLD) family (see Table 1)
– 2,500 to 16,000 usable gates
– 282 to 1,500 registers
■ System-level features
– In-circuit reconfigurability (ICR) via external configuration
devices or intelligent controller
– Fully compliant with the peripheral component interconnect
Special Interest Group (PCI SIG) PCI Local Bus Specification,
Revision 2.2 for 5.0-V operation
– Built-in Joint Test Action Group (JTAG) boundary-scan test (BST)
circuitry compliant with IEEE Std. 1149.1-1990 on selected devices
–MultiVolt
TM
I/O interface enabling device core to run at 5.0 V,
while I/O pins are compatible with 5.0-V and 3.3-V logic levels
– Low power consumption (typical specification is 0.5 mA or less in
standby mode)
■ Flexible interconnect
–FastTrack
®
Interconnect continuous routing structure for fast,
predictable interconnect delays
– Dedicated carry chain that implements arithmetic functions such
as fast adders, counters, and comparators (automatically used by
software tools and megafunctions)
– Dedicated cascade chain that implements high-speed, high-fan-in
logic functions (automatically used by software tools and
megafunctions)
– Tri-state emulation that implements internal tri-state nets
■ Powerful I/O pins
■ Programmable output slew-rate control reduces switching noise
Table 1. FLEX 8000 Device Features
Feature EPF8282A
EPF8282AV
EPF8452A EPF8636A EPF8820A EPF81188A EPF81500A
Usable gates 2,500 4,000 6,000 8,000 12,000 16,000
Flipflops 282 452 636 820 1,188 1,500
Logic array blocks (LABs) 26 42 63 84 126 162
Logic elements (LEs) 208 336 504 672 1,008 1,296
Maximum user I/O pins 78 120 136 152 184 208
