Atmel AT86RF215 Device Family
Sub-1GHz/2.4GHz Transceiver and I/Q Radio for
IEEE Std 802.15.4
TM
-2015
IEEE Std 802.15.4g
TM
-2012
ETSI TS 102 887-1
AT86RF215 / AT86RF215IQ / AT86RF215M
DATASHEET
Features AT86RF215
Fully integrated radio transceiver covering 389.5-510MHz / 779-1020MHz / 2400-
2483.5MHz including:
European band: 863-870MHz / 870-876MHz / 915-921MHz
Chinese band: 470-510MHz / 779-787MHz
North American band: 902-928MHz
Korean band: 917-923.5MHz
Japanese band: 920-928MHz
World-wide ISM band: 2400-2483.5MHz
I/Q data interface:
One TX and two RX serial low voltage differential signal (LVDS) interfaces
13-bit I/Q data interface with a sampling frequency of up to 4MHz
Transceiver Control interface: SPI (serial peripheral interface)
Supported PHYs (*proprietary)
MR-FSK
Symbol rates: 50, 100, 150, 200, 300*, 400ksymbol/s
Rate 1/2-FEC: RSC and NRNSC, with and without interleaving
Order: 2-level, 4-level
MR-OFDM
Option 1: 100, 200, 400, 800, 1200*, 1600*, 2400*kb/s
Option 2: 50, 100, 200, 400, 600, 800, 1200*kb/s
Option 3: 50, 100, 200, 300, 400, 600kb/s
Option 4: 50, 100, 150, 200, 300kb/s
MR-O-QPSK
100kchip/s with 6.25, 12.5, 25, 50kb/s data rate
200kchip/s with 12.5, 25*, 50*, 100*kb/s data rate
1000kchip/s with 31.25, 125, 250, 500kb/s data rate
2000kchip/s with 31.25, 125, 250, 500, 1000*kb/s data rate
O-QPSK
1000kchip/s with 250kb/s and 500*kb/s data rate
2000kchip/s with 250kb/s and 1000*kb/s data rate
Bi-directional differential RF signal ports for:
Band I: 433/470/780/863/868/915/917/920MHz
Band II: 2450MHz
Atmel-42415E-WIRELESS-RF215_Datasheet_052016
