AT86RF233-ZU 用户编程技术手册 - ATMEL（爱特美尔）
制造商:
ATMEL（爱特美尔）
分类:
接口芯片
封装:
QFN-32
描述:
AT86RF23x 2.4GHz 射频收发器这些 **AT86RF23x** 低功率 2.4GHz、符合 IEEE 802.15.4 的收发器设计用于工业和消耗高数据传输率的应用。射频范围：2405 至 2480MHz 射频输出功率：高达 +4dBm (AT86RF233)，高达 +3dBm (AT86RF231) 接收器灵敏度：-101dBm @ 250kbps，1% PER 调制：O-QPSK，具有 2000kchip/sec DSSS 支持跳频 (FHSS) OTA 数据传输率：高达 2Mbps FCS 生成/检查和透明通道评估 RSSI 测量、能量检测和链路质量指示 自动确认，CSMA-CA 和重新传送 自动地址过滤 支持 Rx 天线分集 AES-128 安全模块 真随机编号发生器 (TRNG) 128 字节 Tx/Rx FIFO 数据缓冲器 主机通信：串行 SPI 电池监测 各种低功率操作模式 电源：+1.8V 至 +3.6V 直流 工作温度范围：-40 至 +85°C AT86RF231 符合 IEEE 802.15.4-2006，适用于 ZigBee、6LoWPAN、RF4CE、SP100 和 WirelessHART 系统 AT86RF233 符合 IEEE 802.15.4-2011，适用于 ZigBee、6LoWPAN 和 RF4CE 系统 应用：家庭和楼宇自动化、照明系统 、无线传感器网络、物联网 (IoT) 本地通信 **RS 产品代码** 696-3367 AT86RF231-ZU 769-2687 AT86RF233-ZU ### 认可ETSI，FCC，ARIB### 单芯片组件，ATMEL展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P3Hot
原理图在P4P8P10P11P12P13P107P111P117P120P123P155
封装尺寸在P205
型号编码规则在P204
封装信息在P204
焊接温度在P204
功能描述在P76
技术参数、封装参数在P185P187P189P210
应用领域在P1
电气规格在P185
导航目录
AT86RF233-ZU数据手册
Page:
of 217 Go
若手册格式错乱，请下载阅览PDF原文件
1
8351D–MCU Wireless–08/13
AT86RF233
Features
• High Performance RF-CMOS 2.4GHz radio transceiver targeted for
IEEE
®
802.15.4, ZigBee
®
, RF4CE, 6LoWPAN, and ISM applications
• Industry leading link budget:
- Receiver sensitivity -101dBm
- Programmable TX output power from -17dBm up to +4dBm
• Ultra-low current consumption:
- DEEP_SLEEP = 0.02µA
- TRX_OFF = 300µA
- RX_ON = 11.8mA (LISTEN)
• Smart Receiving Techniques enable further current reduction in LISTEN
mode between 10 to 50% from 11.8mA
• Desensitation will enable further reduction up to 1mA
- BUSY_TX = 13.8mA (at max. transmit power)
• Ultra-low supply voltage (1.8V to 3.6V) with internal regulator
• Support for coin cell operation
• Optimized for low BoM Cost and ease of production:
- Few external components necessary (crystal, capacitors and antenna)
• Easy to use interface:
- Registers, frame buffer, and AES accessible through fast SPI
- Only two microcontroller GPIO lines necessary
- One interrupt pin from radio transceiver
- Clock output with prescaler from radio transceiver
• Radio transceiver features:
- 128-byte FIFO (SRAM) for data buffering
- Fully integrated, fast settling PLL to support Frequency Hopping
- Supports 500kHz channel spacing
- Battery monitor and Fast Wake-Up Time < 0.4msec
• Special IEEE 802.15.4
™
-2011 hardware support:
- FCS computation and Clear Channel Assessment
- RSSI measurement, Energy Detection and Link Quality Indication
• MAC hardware accelerator:
- Automated acknowledgement, CSMA-CA and retransmission
- Automatic address filtering
- Automated FCS check
• Extended feature set hardware support:
- AES 128-bit hardware accelerator
- Antenna Diversity and RX/TX indication
- Supported PSDU data rates: 250kb/s, 500kb/s, 1000kb/s and 2000kb/s
- True Random Number Generation for security application
- Reduced Power Consumption modes
- Time and phase measurement support
• Industrial temperature range:
- -40°C to +85°C
• I/O and packages:
- 32-pin Low-Profile QFN Package 5 x 5 x 0.9mm³
- RoHS/Fully Green
• Compliant to EN 300 328/440, FCC-CFR-47 Part 15, ARIB STD-66, RSS-210
• Compliant to IEEE 802.15.4-2003/2006/2011
Low Power,
2.4GHz
Transceiver for
ZigBee, RF4CE,
IEEE 802.15.4,
6LoWPAN, and
ISM
Applications
AT86RF233
Rev. 8351D–MCU Wireless–08/13
