2
T89C51RD2
4243G–8051–05/03
Description T89C51RD2 is high performance CMOS Flash version of the 80C51 CMOS single chip
8-bit microcontroller. It contains a 64 Kbytes Flash memory block for program and for
data.
The 64 Kbytes Flash memory can be programmed either in parallel mode or in serial
mode with the ISP capability or with software. The programming voltage is internally
generated from the standard V
CC
pin.
The T89C51RD2 retains all features of the ATMEL 80C52 with 256 bytes of internal
RAM, a 7-source 4-level interrupt controller and three timer/counters.
In addition, the T89C51RD2 has a Programmable Counter Array, an XRAM of 1024
bytes, an EEPROM of 2048 bytes, a Hardware Watchdog Timer, a more versatile serial
channel that facilitates multiprocessor communication (EUART) and a speed improve-
ment mechanism (X2 mode). Pinout is either the standard 40/44 pins of the C52 or an
extended version with 6 ports in a 64/68 pins package.
The fully static design of the T89C51RD2 allows to reduce system power consumption
by bringing the clock frequency down to any value, even DC, without loss of data.
The T89C51RD2 has 2 software-selectable modes of reduced activity for further reduc-
tion in power consumption. In the idle mode the CPU is frozen while the peripherals and
the interrupt system are still operating. In the power-down mode the RAM is saved and
all other functions are inoperative.
The added features of the T89C51RD2 makes it more powerful for applications that
need pulse width modulation, high speed I/O and counting capabilities such as alarms,
motor control, corded phones, smart card readers.
Table 1. Memory Size
PDIL40
PLCC44
VQFP44 1.4 Flash (bytes)
EEPROM
(bytes) XRAM (bytes)
TOTAL RAM
(bytes) I/O
T89C51RD2 64K 2K 1024 1280 32
PLCC68
VQFP64 1.4 Flash (bytes)
EEPROM
(bytes) XRAM (bytes)
TOTAL RAM
(bytes) I/O
T89C51RD2 64K 2K 1024 1280 48
