Atmel-7766IS-USB-ATmega16U4/32U4-Datasheet_Summary_072015
Features
• High Performance, Low Power AVR
®
8-Bit Microcontroller
• Advanced RISC Architecture
– 135 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
– Up to 16 MIPS Throughput at 16MHz
– On-Chip 2-cycle Multiplier
• Non-volatile Program and Data Memories
– 16/32KB of In-System Self-Programmable Flash
– 1.25/2.5KB Internal SRAM
– 512Bytes/1KB Internal EEPROM
– Write/Erase Cycles: 10,000 Flash/100,000 EEPROM
– Data retention: 20 years at 85C/ 100 years at 25C
(1)
– Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
Parts using external XTAL clock are pre-programed with a default USB bootloader
– Programming Lock for Software Security
• JTAG (IEEE
®
std. 1149.1 compliant) Interface
– Boundary-scan Capabilities According to the JTAG Standard
– Extensive On-chip Debug Support
– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface
• USB 2.0 Full-speed/Low Speed Device Module with Interrupt on Transfer Completion
– Complies fully with Universal Serial Bus Specification Rev 2.0
– Supports data transfer rates up to 12Mbit/s and 1.5Mbit/s
– Endpoint 0 for Control Transfers: up to 64-bytes
– Six Programmable Endpoints with IN or Out Directions and with Bulk, Interrupt or
Isochronous Transfers
– Configurable Endpoints size up to 256 bytes in double bank mode
– Fully independent 832 bytes USB DPRAM for endpoint memory allocation
– Suspend/Resume Interrupts
– CPU Reset possible on USB Bus Reset detection
– 48MHz from PLL for Full-speed Bus Operation
– USB Bus Connection/Disconnection on Microcontroller Request
– Crystal-less operation for Low Speed mode
• Peripheral Features
– On-chip PLL for USB and High Speed Timer: 32 up to 96MHz operation
– One 8-bit Timer/Counter with Separate Prescaler and Compare Mode
ATmega16U4/ATmega32U4
8-bit Microcontroller with 16/32K bytes of ISP Flash and
USB Controller
DATASHEET SUMMARY
