8-bit AVR Microcontroller
ATmega48PB/88PB/168PB
DATASHEET COMPLETE
Introduction
Atmel
®
ATmega48PB/88PB/168PB is a low-power CMOS 8-bit
microcontroller based on the AVR enhanced RISC architecture. By executing
powerful instructions in a single clock cycle, the ATmega48PB/88PB/168PB
achieves throughputs approaching 1MIPS/MHz, allowing the system
designer to optimize power consumption versus processing speed.
Features
• Advanced RISC architecture
– 131 instructions – most single clock cycle execution
– 32 x 8 general purpose working registers
– Fully static operation
– Up to 20MIPS throughput at 20MHz
– On-chip 2-cycle Multiplier
• High endurance non-volatile memory segments
– 4/8/16KBytes of in-system self-programmable Flash program
memory
– 256/512/512Bytes EEPROM
– 512/1K/1KBytes internal SRAM
– Write/Erase cycles: 10,000 Flash/100,000 EEPROM
– Data retention: 20 years at 85°C/100 years at 25°C
– Optional boot code section with independent lock bits
• In-system programming by on-chip boot program
• True Read-While-Write (RWW) operation
– Programming lock for software security
• Atmel
®
QTouch
®
library support
– Capacitive touch buttons, sliders and wheels
– QTouch and QMatrix
®
acquisition
– Up to 64 sense channels
• Peripheral Features
– Two 8-bit Timer/Counters (TC) with separate prescaler and
compare mode
Atmel-42176G-ATmega48PB/88PB/168PB_Datasheet_Complete-03/2016
