QFN32 pin
number
Mnemonic Type Name, function, and alternate function
28 PB7 I/O ADC4 (Analog Input Channel 4)
PSCOUT0B
(1)
(PSC Module 0 Output B)
SCK (SPI Clock)
PCINT7 (Pin Change Interrupt 7)
30 PC0 I/O PSCOUT1A
(1)
(PSC Module 1 Output A)
INT3 (External Interrupt 3 Input)
PCINT8 (Pin Change Interrupt 8)
3 PC1 I/O PSCIN1 (PSC Digital Input 1)
OC1B (Timer 1 Output Compare B)
SS_A (Alternate SPI Slave Select)
PCINT9 (Pin Change Interrupt 9)
6 PC2 I/O T0 (Timer 0 clock input)
TXCAN (CAN Transmit Output)
PCINT10 (Pin Change Interrupt 10)
7 PC3 I/O T1 (Timer 1 clock input)
RXCAN (CAN Receive Input)
ICP1B (Timer 1 input capture alternate B input)
PCINT11 (Pin Change Interrupt 11)
17 PC4 I/O ADC8 (Analog Input Channel 8)
AMP1- (Analog Differential Amplifier 1 Negative Input)
ACMPN3 (Analog Comparator 3 Negative Input )
PCINT12 (Pin Change Interrupt 12)
18 PC5 I/O ADC9 (Analog Input Channel 9)
AMP1+ (Analog Differential Amplifier 1 Positive Input)
ACMP3 (Analog Comparator 3 Positive Input)
PCINT13 (Pin Change Interrupt 13)
22 PC6 I/O ADC10 (Analog Input Channel 10)
ACMP1 (Analog Comparator 1 Positive Input)
PCINT14 (Pin Change Interrupt 14)
25 PC7 I/O D2A (DAC output)
AMP2+ (Analog Differential Amplifier 2 Positive Input)
PCINT15 (Pin Change Interrupt 15)
29 PD0 I/O PSCOUT0A
(1)
(PSC Module 0 Output A)
PCINT16 (Pin Change Interrupt 16)
Atmel ATmega16M1/32M1/64M1 [DATASHEET]
Atmel-8209F-ATmega16M1/32M1/64M1_Datasheet_Summary-10/2016
6
