8-bit AVR Microcontroller
ATmega32A
DATASHEET SUMMARY
Introduction
The Atmel
®
ATmega32A is a low-power CMOS 8-bit microcontroller based
on the AVR
®
enhanced RISC architecture. By executing powerful instructions
in a single clock cycle, the ATmega32A achieves throughputs close to
1MIPS per MHz. This empowers system designer to optimize the device for
power consumption versus processing speed.
Features
• High-performance, Low-power Atmel AVR 8-bit Microcontroller
• Advanced RISC Architecture
– 131 Powerful Instructions - Most Single-clock Cycle Execution
– 32 × 8 General Purpose Working Registers
– Fully Static Operation
– Up to 16MIPS Throughput at 16MHz
– On-chip 2-cycle Multiplier
• High Endurance Non-volatile Memory segments
– 32Kbytes of In-System Self-programmable Flash program
memory
– 1024Bytes EEPROM
– 2Kbytes Internal SRAM
– Write/Erase cycles: 10,000 Flash/100,000 EEPROM
– Data retention: 20 years at 85°C/100 years at 25°C
(1)
– Optional Boot Code Section with Independent Lock Bits
• In-System Programming by On-chip Boot Program
• True Read-While-Write Operation
– Programming Lock for Software Security
• JTAG (IEEE std. 1149.1 Compliant) Interface
– Boundary-scan Capabilities According to the JTAG Standard
– Extensive On-chip Debug Support
– Programming of Flash, EEPROM, Fuses and Lock Bits through
the JTAG Interface
• Atmel QTouch
®
library support
Atmel-8155G-8-bit AVR-ATmega32A_Datasheet_Summary-10/2015
This is a summary document. A
complete document is available
on our Web site at
www.atmel.com
