8-bit AVR Microcontrollers
ATmega48P/PV / 88P/PV / 168P/PV
DATASHEET SUMMARY
Introduction
The Atmel
®
picoPower
®
ATmega48P/PV /88P/PV /168P/PV is a low-power
CMOS 8-bit microcontroller based on the AVR
®
enhanced RISC
architecture. By executing powerful instructions in a single clock cycle, the
ATmega48P/PV /88P/PV /168P/PV achieves throughputs close to 1MIPS
per MHz. This empowers system designer to optimize the device for power
consumption versus processing speed.
Feature
High Performance, Low Power Atmel
®
AVR
®
8-Bit Microcontroller Family
• Advanced RISC Architecture
– 131 Powerful Instructions
– Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
– Up to 20 MIPS Throughput at 20MHz
– On-chip 2-cycle Multiplier
• High Endurance Non-volatile Memory Segments
– 4K/8K/16KBytes of In-System Self-Programmable Flash program
Memory
– 256/512/512Bytes EEPROM
– 512/1K/1KBytes Internal SRAM
– Write/Erase Cycles: 10,000 Flash/100,000 EEPROM
– Data Retention: 20 years at 85°C/100 years at 25°C
(1)
– Optional Boot Code Section with Independent Lock Bits
• In-System Programming by On-chip Boot Program
• True Read-While-Write Operation
– Programming Lock for Software Security
• Atmel
®
QTouch
®
Library Support
– Capacitive Touch Buttons, Sliders and Wheels
– QTouch and QMatrix
®
Acquisition
– Up to 64 sense channels
Atmel-8025P-ATmega48P/PV/88P/PV/168P/PV_Datasheet_Summary-11/2016
