Micro Programmable Controller
CPM1A
A--22
Micro Programmable Controller
CPM1A
The CPM1A series micro controllers solve both
basic and semi-complex applications. The brick
style models include DC inputs/transistor or
relay outputs to meet your design
requirements. The base I/O for the CPUs
ranges from 10, 20, 30, and 40 I/O points with
maximum expansion to 100 I/O. Specialized
expansion modules include mixed analog I/O,
temperature sensor inputs and serial
communications.
D
10, 20, 30 and 40 point I/O CPUs
D
Expandable up to 100 I/O points
D
Peripheral communications port built in
D
DC input models
D
Analog expansion modules available
D
Temperature sensor input expansion modules available
D
Auxiliary 24 VDC supply (AC type only)
D
Relay or Transistor outputs
D
UL, CSA, CE approvals
Basic Configuration
CPM1-CIF01/CIF11 Serial
Communications Adaptor
