3
82C54
Absolute Maximum Ratings Thermal Information
Supply Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +8.0V
Input, Output or I/O Voltage . . . . . . . . . . . . GND-0.5V to V
CC
+0.5V
ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class 1
Operating Conditions
Operating Voltage Range. . . . . . . . . . . . . . . . . . . . . . +4.5V to +5.5V
Operating Temperature Range
CX82C54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to +70°C
IX82C54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to +85°C
MD82C54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-55°C to +125°C
Thermal Resistance (Typical)
JA
(
o
C/W)
JC
(
o
C/W)
CERDIP Package. . . . . . . . . . . . . . . . . 55 12
CLCC Package . . . . . . . . . . . . . . . . . . 65 14
PDIP Package* . . . . . . . . . . . . . . . . . . 55 N/A
PLCC Package. . . . . . . . . . . . . . . . . . . 60 N/A
Storage Temperature Range . . . . . . . . . . . . . . . . . .-65°C to +150°C
Maximum Junction Temperature Ceramic Package . . . . . . . +175°C
Maximum Junction Temperature Plastic Package. . . . . . . . . +150°C
Maximum Lead Temperature Package (Soldering 10s). . . . . +300°C
(PLCC - Lead Tips Only)
*Pb-free PDIPs can be used for through hole wave solder
processing only. They are not intended for use in Reflow solder
processing applications.
Die Characteristics
Gate Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2250 Gates
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
DC Electrical Specifications V
CC
= +5.0V ± 10%, Includes all Temperature Ranges
SYMBOL PARAMETER MIN MAX UNITS TEST CONDITIONS
VIH Logical One Input Voltage 2.0 - V CX82C54, IX82C54
2.2 - V MD82C54
VIL Logical Zero Input Voltage - 0.8 V -
VOH Output HIGH Voltage 3.0 - V IOH = -2.5mA
V
CC
-0.4 - V IOH = -100A
VOL Output LOW Voltage - 0.4 V IOL = +2.5mA
II Input Leakage Current -1 +1 A VIN = GND or V
CC
DIP Pins 9,11,14-16,18-23
IO Output Leakage Current -10 +10 A VOUT = GND or V
CC
DIP Pins 1-8
ICCSB Standby Power Supply Current - 10 AV
CC
= 5.5V, VIN = GND or V
CC
,
Outputs Open, Counters
Programmed
ICCOP Operating Power Supply Current - 10 mA V
CC
= 5.5V,
CLK0 = CLK1 = CLK2 = 8MHz,
VIN = GND or V
CC
,
Outputs Open
Capacitance T
A
= +25
o
C; All Measurements Referenced to Device GND, Note 1
SYMBOL PARAMETER TYP UNITS TEST CONDITIONS
CIN Input Capacitance 20 pF FREQ = 1MHz
COUT Output Capacitance 20 pF FREQ = 1MHz
CI/O I/O Capacitance 20 pF FREQ = 1MHz
NOTE:
1. Not tested, but characterized at initial design and at major process/design changes.
