82C54
Ordering Information
PART NUMBERS
TEMP RANGE
(°C) PACKAGE
PKG.
DWG. #8MHz 10MHz 12MHz
CP82C54 CP82C54-10 (No longer available,
recommended replacement:
CP82C54-10Z)
CP82C54-12
(No longer
available,
recommended
replacement:
CP82C54-12Z)
0 to +70 24 Lead PDIP E24.6
CP82C54Z (See Note) CP82C54-10Z (See Note) CP82C54-12Z
(See Note)
0 to +70 24 Lead PDIP** (Pb-free) E24.6
CS82C54* CS82C54-10* CS82C54-12
(No longer
available,
recommended
replacement:
CS82C54-12Z)
0 to +70 28 Lead PLCC N28.45
CS82C54Z* (See Note) CS82C54-10Z* (See Note) CS82C54-12Z*
(See Note)
0 to +70 28 Lead PLCC (Pb-free) N28.45
ID82C54 - - -40 to +85 24 Lead CERDIP F24.6
IP82C54 IP82C54-10 - -40 to +85 24 Lead PDIP E24.6
IP82C54Z (See Note) IP82C54-10Z (See Note) - -40 to +85 24 Lead PDIP** (Pb-free) E24.6
IS82C54* IS82C54-10* - -40 to +85 28 Lead PLCC N28.45
IS82C54Z (See Note) IS82C54-10Z (See Note) - -40 to +85 28 Lead PLCC (Pb-free) N28.45
MD82C54/B - - -55 to +125 24 Lead CERDIP F24.6
SMD # 8406501JA - - -55 to +125 24 Lead CERDIP F24.6
SMD# 84065013A - 84065023A -55 to +125 28 Lead CLCC J28.A
Contact factory for availability.
*Add “96” suffix for tape and reel.
**Pb-free PDIPs can be used for through hole wave solder processing only. They are not intended for use in Reflow solder processing applications.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free material sets; molding compounds/die attach materials and 100% matte tin
plate termination finish, which are RoHS compliant and compatible with both SnPb and Pb-free soldering operations. Intersil Pb-free products are
MSL classified at Pb-free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.
