© 2009 Microchip Technology Inc. DS70152G-page 3
dsPIC33F/PIC24H PROGRAMMING SPECIFICATION
2.4 Memory Map
The program memory map extends from 0x0 to
0xFFFFFE. Code storage is located at the base of the
memory map and supports up to 88K instructions
(about 256 Kbytes). Table 2-2 shows the program
memory size and number of erase and program blocks
present in each device variant. Each erase block or
page contains 512 instructions and each program block
or row, contains 64 instructions.
Locations 0x800000 through 0x800FFE are reserved
for executive code memory. This region stores the
programming executive and the debugging
executive. The programming executive is used for
device programming and the debug executive is
used for in-circuit debugging. This region of memory
cannot be used to store user code.
Locations 0xF80000 through 0xF80017 are reserved
for the device Configuration registers.
Locations 0xFF0000 and 0xFF0002 are reserved for
the Device ID Word registers. These bits can be used
by the programmer to identify which device type is
being programmed. They are described in Section 7.0
“Device ID”. The Device ID registers read out
normally, even after code protection is applied.
Figure 2-3 shows the memory map for the dsPIC33F/
PIC24H family variants.
TABLE 2-2: CODE MEMORY SIZE
dsPIC33F/PIC24H Device
User Memory Address
Limit
(Instruction Words)
Write Blocks Erase Blocks
Executive Memory
Address Limit
(Instruction Words)
dsPIC33FJ06GS101 0x000FFE (2K) 32 4 0x8007FE (1K)
dsPIC33FJ06GS102 0x000FFE (2K) 32 4 0x8007FE (1K)
dsPIC33FJ06GS202 0x000FFE (2K) 32 4 0x8007FE (1K)
dsPIC33FJ16GS402 0x002BFE (6K) 88 11 0x8007FE (1K)
dsPIC33FJ16GS404 0x002BFE (6K) 88 11 0x8007FE (1K)
dsPIC33FJ16GS502 0x002BFE (6K) 88 11 0x8007FE (1K)
dsPIC33FJ16GS504 0x002BFE (6K) 88 11 0x8007FE (1K)
dsPIC33FJ12GP201 0x001FFE (4K) 64 8 0x8007FE (1K)
dsPIC33FJ12GP202 0x001FFE (4K) 64 8 0x8007FE (1K)
dsPIC33FJ16GP304 0x002BFE (6K) 88 11 0x800FFE (2K)
dsPIC33FJ32GP202 0x0057FE (11K) 176 22 0x800FFE (2K)
dsPIC33FJ32GP204 0x0057FE (11K) 176 22 0x800FFE (2K)
dsPIC33FJ32GP302 0x0057FE (11K) 176 22 0x800FFE (2K)
dsPIC33FJ32GP304 0x0057FE (11K) 176 22 0x800FFE (2K)
dsPIC33FJ64GP202 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP204 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP206 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP306 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP310 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP706 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP708 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP710 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP802 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ64GP804 0x00ABFE (22K) 344 43 0x800FFE (2K)
dsPIC33FJ128GP202 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP204 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP206 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP306 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP310 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP706 0x0157FE (44K) 688 86 0x800FFE (2K)
dsPIC33FJ128GP708 0x0157FE (44K) 688 86 0x800FFE (2K)
