2 Altera Corporation
APEX 20KC Programmable Logic Device Data Sheet
...and More
Features
■
Low-power operation design
– 1.8-V supply voltage (see Table 2)
– Copper interconnect reduces power consumption
–MultiVolt
TM
I/O support for 1.8-V, 2.5-V, and 3.3-V interfaces
– ESBs offering programmable power-saving mode
■
Flexible clock management circuitry with up to four phase-locked
loops (PLLs)
– Built-in low-skew clock tree
– Up to eight global clock signals
– ClockLock
TM
feature reducing clock delay and skew
–ClockBoost
TM
feature providing clock multiplication and
division
– ClockShift
TM
feature providing programmable clock phase and
delay shifting
■
Powerful I/O features
– Compliant with peripheral component interconnect Special
Interest Group (PCI SIG) PCI Local Bus Specification,
Revision 2.2 for 3.3-V operation at 33 or 66 MHz and 32 or 64 bits
– Support for high-speed external memories, including DDR
synchronous dynamic RAM (SDRAM) and ZBT static RAM
(SRAM)
– 16 input and 16 output LVDS channels at 840 megabits per
second (Mbps)
– Direct connection from I/O pins to local interconnect providing
fast t
CO
and t
SU
times for complex logic
– MultiVolt I/O support for 1.8-V, 2.5-V, and 3.3-V interfaces
– Programmable clamp to V
CCIO
– Individual tri-state output enable control for each pin
– Programmable output slew-rate control to reduce switching
noise
– Support for advanced I/O standards, including low-voltage
differential signaling (LVDS), LVPECL, PCI-X, AGP, CTT,
SSTL-3 and SSTL-2, GTL+, and HSTL Class I
– Supports hot-socketing operation
– Pull-up on I/O pins before and during configuration
Note to Table 2:
(1) APEX 20KC devices can be 5.0-V tolerant by using an external resistor.
Table 2. APEX 20KC Supply Voltages
Feature Voltage
Internal supply voltage (V
CCINT
) 1.8 V
MultiVolt I/O interface voltage levels (V
CCIO
) 1.8 V, 2.5 V, 3.3 V, 5.0 V (1)
