DS019 (v1.9) February 8, 2008 www.xilinx.com
Product Specification 1
© 1998–-2008 Xilinx, Inc. All rights reserved. XILINX, the Xilinx logo, the Brand Window, and other designated brands included herein are trademarks of Xilinx, Inc. All other
trademarks are the property of their respective owners.
This product is undergoing discontinuance. Please refer to XCN07022, Product Discontinuation Notice, for more
information on last-time purchases and replacement products.
Device and Package Support
• XC1700/XC17S00/XL Serial PROMs
• XC17V00/XC17S00A Serial PROMs
• XC18V00 ISP PROMs
• XC9500/XL/XV CPLDs
• XCR3000XL CPLDs
• Supports all Xilinx package types
Programmer Accessories
• Universal power supply
• Power cord options for US, Asia, UK, European and
Japanese standards
• Serial download cable and adapters
• User’s manual
• Programmer interface software
• Vacuum handling tool
Interface Software and System
Requirements
The programmer software operates on a Windows 32-bit
platform. Ta ble 1 indicates the minimum system
requirements for each. In all cases, a CD-ROM drive and an
RS-232 serial port are required. A mouse is recommended.
Programmer Functional Specifications
• Device programming, erasing, and verification
• CPLD security control
• Serial PROM reset polarity control
• Checksum calculation and comparison
• Blank check and signature ID tests
• Master device upload
• File transfer and comparison
• Self check and auto calibration
• Intended for development — not recommended for
production programming
Programming Socket Adapters
• Supports all package styles: PLCC, PQFP, TQFP,
VQFP, HQFP, BGA, FBGA, SOIC, VOIC, CSP and DIP
• Purchase as needed for specific package support
Electrical Requirements and Physical
Specifications
• Operating voltage: 100-250 VAC, 50-60 Hz
• Power consumption: 0.5 Amp
• Dimensions: programmer – 6 x 8 x 2 inches; power
supply – 3 x 5 x 1.75 inches
• Weight: programmer – 1.2 lb.; power supply – 1.3 lb.
• Safety standards: approved by UL, CSA, TUV, CE
New Programming Algorithm Support
The new programming algorithms are available via the Xilinx
FTP site. Download the latest programming software from:
ftp://ftp.xilinx.com/pub/swhelp/programmer/hw130w32.exe
Ordering Information
0
HW-130 Programmer
DS019 (v1.9) February 8, 2008
00
Product Specification
R
Ta b l e 1 : Interface Software and System Requirements
Requirements
Windows Version
95 98 NT 2000/XP
Memory 8 MB 16 MB 16 MB 16 MB
Hard Disk Space 15 MB 15 MB 15 MB 15 MB
HW-130 Host
Software
4.00 or
greater
4.10 or
greater
3.1 or
greater
5.06 or
greater
Part Part Number
HW-130 Programmer for USA/Asia HW-130-US
HW-130 Programmer for Europe HW-130-EC
HW-130 Programmer for United Kingdom HW-130-UK
HW-130 Programmer for Japan HW-130-J
