TUTORIAL 3189

Programmers Handbook for the MAX5290-MAX5295,

MAX5580-MAX5585, MAX5590-MAX5595 User-

Programmable DACs

Jun 27, 2004

SCLK - serial clock input. Data may be clocked into, and out of, the serial interface on either rising or falling

clock edges, depending on configuration.

DIN - serial data input.

CS - active-low chip select. For all modes except the DSP Frame Sync mode, the falling edge of CS

corresponds to the start of the serial interface command, and the rising edge of CS corresponds to the end

of the command.

DSP - DSP is sampled at the end of the power-on reset sequence, and its state determines the active edge

of the SCLK signal for clocking in data at DIN. Connect DSP to DV

DD

to clock in data on the rising edge of

timing specifications and device configurations.

Any device within the family is capable of supporting a wide range of configurations, including (but not limited to)

the following:

Write operation to a single device
