TPU Programming Library
TPUPN06/D 3
4 Function Parameters
This section provides detailed descriptions of function parameters stored in channel parameter RAM.
Figure 2
shows TPU parameter RAM address mapping.
Figure 3
shows the parameter RAM assign-
ment used by the function. In the diagrams, Y = M111, where M is the value of the module mapping bit
(MM) in the system integration module configuration register (Y = $7 or $F).
— = Not Implemented (reads as $00)
Figure 2 TPU Channel Parameter RAM CPU Address Map
W = Channel Number
Figure 3 Parameter RAM Assignment
Channel Base Parameter Address
Number Address 01234567
0 $YFFF## 00 02 04 06 08 0A — —
1 $YFFF## 10 12 14 16 18 1A — —
2 $YFFF## 20 22 24 26 28 2A — —
3 $YFFF## 30 32 34 36 38 3A — —
4 $YFFF## 40 42 44 46 48 4A — —
5 $YFFF## 50 52 54 56 58 5A — —
6 $YFFF## 60 62 64 66 68 6A — —
7 $YFFF## 70 72 74 76 78 7A — —
8 $YFFF## 80 82 84 86 88 8A — —
9 $YFFF## 90 92 94 96 98 9A — —
10 $YFFF## A0 A2 A4 A6 A8 AA — —
11 $YFFF## B0 B2 B4 B6 B8 BA — —
12 $YFFF## C0 C2 C4 C6 C8 CA — —
13 $YFFF## D0 D2 D4 D6 D8 DA — —
14 $YFFF## E0 E2 E4 E6 E8 EA EC EE
15 $YFFF## F0 F2 F4 F6 F8 FA FC FE
1514131211109876543210
$YFFFW0
CHANNEL_CONTROL
$YFFFW2
MAX_COUNT PERIOD_COUNT
$YFFFW4
LAST_TIME
$YFFFW6
ACCUM
$YFFFW8
HW
$YFFFWA
LW
Parameter Write Access
Written by CPU
Written by TPU
Written by CPU and TPU
Unused parameters
