Order this document
by MC68HC11FTS/D
© MOTOROLA INC., 1997
This document contains information on a new product. Specifications and information herein are subject to change without notice.
ATA
M
MC68HC11F1
MC68HC11FC0
Technical Summary
8-Bit Microcontroller
1 Introduction
The MC68HC11F1 is a high-performance member of the M68HC11 family of microcontroller units
(MCUs). High-speed expanded systems required the development of this chip with its extra input/output
(I/O) ports, an increase in static RAM (one Kbyte), internal chip-select functions, and a non-multiplexed
bus which reduces the need for external interface logic. The timer, serial I/O, and analog-to-digital (A/
D) converter enable functions similar to those found in the MC68HC11E9.
The MC68HC11FC0 is a low cost, high-speed derivative of the MC68HC11F1. It does not have
EEPROM or an analog-to-digital converter. The MC68HC11FC0 can operate at bus speeds as high as
six MHz.
This document provides a brief overview of the structure, features, control registers, packaging infor-
mation and availability of the MC68HC11F1 and MC68HC11FC0. For detailed information on
M68HC11 subsystems, programming and the instruction set, refer to the
M68HC11 Reference Manual
(M68HC11RM/AD).
1.1 Features
• MC68HC11 CPU
• 512 Bytes of On-Chip Electrically Erasable Programmable ROM (EEPROM) with Block Protect
(MC68HC11F1 only)
• 1024 Bytes of On-Chip RAM (All Saved During Standby)
• Enhanced 16-Bit Timer System
— 3 Input Capture (IC) Functions
— 4 Output Compare (OC) Functions
— 4th IC or 5th OC (Software Selectable)
• On-Board Chip-Selects with Clock Stretching
• Real-Time Interrupt Circuit
• 8-Bit Pulse Accumulator
• Synchronous Serial Peripheral Interface (SPI)
• Asynchronous Nonreturn to Zero (NRZ) Serial Communication Interface (SCI)
• Power saving STOP and WAIT Modes
• Eight-Channel 8-Bit A/D Converter (MC68HC11F1 only)
• Computer Operating Properly (COP) Watchdog System and Clock Monitor
• Bus Speeds of up to 6 MHz for the MC68HC11FC0 and up to 5 MHz for the MC68HC11F1
• 68-Pin PLCC (MC68HC11F1 only), 64-Pin QFP (MC68HC11FC0 only), and 80-pin TQFP pack-
age options
Freescale Semiconductor, I
nc
.
..
