Concept
• The sensitivity of each Sensor is individually factory calibrated, using 2 EEPROM parameters
RG and FG (RoughGain, FineGain), to reach the target sensitivity, as defined in the
datasheet.
Blind calibration consists in recalibrating parts without performing measurements:
• To do so, it is needed to read and manually change the RG and FG values in the EEPROM.
• These 2 parameters codes for the amplification chain that amplify the signal from the hall
plates.
• Modifying RG, FG allow to change the output sensitivity of a sensor.
Note : Blind calibration is not available for 91206/07 because the TC parameters need to be re-trim when
RG/FG are changed. See slide 23 for more details.
