PIC16(L)F151X/152X
DS41442B-page 2 Advance Information 2010-2011 Microchip Technology Inc.
1.2 Pin Utilization
Five pins are needed for ICSP™ programming. The
pins are listed in Ta bl e 1- 1 and Tab l e 1- 2.
TABLE 1-1: PIN DESCRIPTIONS DURING PROGRAMMING – PIC16(L)F1526 AND PIC16(L)F1527
Pin Name
During Programming
Function Pin Type Pin Description
RB6 ICSPCLK I Clock Input – Schmitt Trigger Input
RB7 ICSPDAT I/O Data Input/Output – Schmitt Trigger Input
RG5/MCLR
/VPP Program/Verify mode P
(1)
Program Mode Select/Programming Power Supply
V
DD VDD P Power Supply
V
SS VSS P Ground
Legend: I = Input, O = Output, P = Power
Note 1: The programming high voltage is internally generated. To activate the Program/Verify mode, high voltage needs to be
applied to MCLR
input. Since the MCLR is used for a level source, MCLR does not draw any significant current.
TABLE 1-2: PIN DESCRIPTIONS DURING PROGRAMMING – PIC16(L)F1512, PIC16(L)F1513,
PIC16(L)F1516
, PIC16(L)F1517, PIC16(L)F1518 and PIC16(L)F1519
Pin Name
During Programming
Function Pin Type Pin Description
RB6 ICSPCLK I Clock Input – Schmitt Trigger Input
RB7 ICSPDAT I/O Data Input/Output – Schmitt Trigger Input
RE3/MCLR
/VPP Program/Verify mode P
(1)
Program Mode Select/Programming Power Supply
V
DD VDD P Power Supply
V
SS VSS P Ground
Legend: I = Input, O = Output, P = Power
Note 1: The programming high voltage is internally generated. To activate the Program/Verify mode, high voltage needs to be
applied to MCLR
input. Since the MCLR is used for a level source, MCLR does not draw any significant current.
