2011 Microchip Technology Inc. Advance Information DS41409B-page 5
PIC16(L)F720/721
3.1 User ID Location
A user may store identification information (user ID) in
four designated locations. The user ID locations are
mapped to 2000h-2003h. Each location is 14 bits in
length. Code protection has no effect on these memory
locations. Each location may be read with code
protection enabled or disabled.
3.2 Device ID
The device ID word for the PIC16F/LF720 and the
PIC16F/LF721 is located at 2006h. This location
cannot be erased or modified.
REGISTER 3-1: DEVICEID: DEVICE ID REGISTER
(1)
TABLE 3-1: DEVICE ID VALUES
Note: MPLAB
®
IDE only displays the 7 Least
Significant bits (LSb) of each user ID
location, the upper bits are not read. It is
recommended that only the 7 LSbs be
used if MPLAB IDE is the primary tool
used to read these addresses.
R-q R-q R-q R-q R-q R-q R-q
DEV8 DEV7 DEV6 DEV5 DEV4 DEV3 DEV2
bit 13 bit 7
R-q R-q R-q R-q R-q R-q R-q
DEV1 DEV0 REV4 REV3 REV2 REV1 REV0
bit 6 bit 0
Legend: P = Programmable bit U = Unimplemented bit, read as ‘0’
R = Readable bit W = Writable bit ‘0’ = Bit is cleared
-n = Value at POR ‘1’ = Bit is set x = Bit is unknown
bit 13-5 DEV<8:0>: Device ID bits
These bits are used to identify the part number.
bit 4-0 REV<4:0>: Revision ID bits
These bits are used to identify the revision.
Note 1: This location cannot be written.
DEVICE
DEVICE ID VALUES
DEV REV
PIC16F720 01 1100 0000 x xxxx
PIC16F721 01 1100 0010 x xxxx
PIC16LF720 01 1100 0100 x xxxx
PIC16LF721 01 1100 0110 x xxxx
