PIC18FX220/X320
DS39592F-page 6 2010 Microchip Technology Inc.
FIGURE 2-8: MEMORY MAP FOR PIC18F1X20
2.3.1 MEMORY ADDRESS POINTER
Memory in the address space, 000000h to 3FFFFFh, is
addressed via the Table Pointer, which is comprised of
three pointer registers:
• TBLPTRU at address 0FF8h
• TBLPTRH at address 0FF7h
• TBLPTRL at address 0FF6h
0000h
200000h
3FFFFFh
Unimplemented
Read as ‘0’s
200h
07FFh
Boot Block
Block 0
8Kbytes
200000h ID Location 1
200001h ID Location 2
200002h ID Location 3
200003h ID Location 4
200004h ID Location 5
200005h ID Location 6
200006h ID Location 7
200007h ID Location 8
300000h CONFIG1L
300001h CONFIG1H
300002h CONFIG2L
300003h CONFIG2H
3FFFFEh Device ID 1
3FFFFFh Device ID 2
4 Kbytes
Block 0
Block 1
Boot Block
Block 1
0FFFh
17FFh
1FFFh
Unimplemented
Read as ‘0’s
TBLPTRU TBLPTRH TBLPTRL
Addr[21:16] Addr[15:8] Addr[7:0]
