2014-2015 Microchip Technology Inc. DS40001772B-page 3
PIC18(L)F2X/4XK40
2.0 MEMORY MAP
TABLE 2-1: PROGRAM AND DATA EEPROM MEMORY MAP
PIC18(L)F24K40
PIC18(L)F25K40
PIC18(L)F45K40
PIC18(L)F26K40
PIC18(L)F46K40
PIC18(L)F27K40
PIC18(L)F47K40
PC<21:0> PC<21:0> PC<21:0> PC<21:0>
Note 1 Stack (31 levels) Stack (31 levels) Stack (31 levels) Stack (31 levels) Note 1
00 0000h Reset Vector Reset Vector Reset Vector Reset Vector 00 0000h
••• ••• ••• ••• ••• •••
00 0008h Interrupt Vector High Interrupt Vector High Interrupt Vector High Interrupt Vector High 00 0008h
••• ••• ••• ••• ••• •••
00 0018h Interrupt Vector Low Interrupt Vector Low Interrupt Vector Low Interrupt Vector Low 00 0018h
00 001Ah
•
00 3FFFh
Program Flash Memory
(8 KW)
Program Flash Memory
(16 KW)
Program Flash Memory
(32 KW)
Program Flash Memory
(64 KW)
00 001Ah
•
00 3FFFh
00 4000h
•
00 7FFFh
Not present
(2)
00 4000h
•
00 7FFFh
00 8000h
•
00 FFFFh
Not present
(2)
00 8000h
•
00 FFFFh
01 0000h
•
01 FFFFh
Not present
(2)
01 0000h
•
01 FFFFh
02 0000h
•
1F FFFFh
Not present
(2)
02 0000h
•
1F FFFFh
20 0000h
•••
20 000Fh
User IDs (8 Words)
(3)
20 0000h
•••
20 000Fh
20 0010h
•••
2F FFFFh
Reserved
20 0010h
•••
2F FFFFh
30 0000h
•••
30 000Bh
Configuration Words (6 Words)
(3)
30 0000h
•••
30 000Bh
30 000Ch
•••
30 FFFFh
Reserved
30 000Ch
•••
30 FFFFh
31 0000h
•••
31 00FFh
DataEEByte0
•••
DataEEByte255
DataEEByte0
•••
DataEEByte1023
31 0000h
•••
•••
31 03FFh
Unimplemented • • •
31 03FFh
31 0400h
•••
3F FFFBh
Reserved
31 0400h
•••
3F FFFBh
3F FFFCh
•••
3F FFFDh
Revision ID (1 Word)
(4)
3F FFFCh
•••
3F FFFDh
3F FFFEh
•••
3F FFFFh
Device ID (1 Word)
(4)
3F FFFEh
•••
3F FFFFh
Note 1: The stack is a separate SRAM panel, apart from all user memory panels.
2: The addresses do not roll over. The region is read as ‘0’.
3: Not code-protected.
4: Device/Revision IDs are hard-coded in silicon.
