PIC18F6XJXX/8XJXX
DS39644L-page 2 2009 Microchip Technology Inc.
TABLE 2-1: PIN DESCRIPTIONS (DURING PROGRAMMING): PIC18F6XJXX/8XJXX
Pin Name
During Programming
Pin Name Pin Type Pin Description
MCLR
MCLR P Programming Enable
VDD and AVDD
(1)
VDD P Power Supply
VSS and AVSS
(1)
VSS PGround
ENVREG ENVREG P Internal Voltage Regulator Enable
V
DDCORE/VCAP VDDCORE P Regulated Power Supply for Microcontroller Core
VCAP I Filter Capacitor for On-Chip Voltage Regulator
RB6 PGC I Serial Clock
RB7 PGD I/O Serial Data
V
USB
(2)
VUSB P Internal USB 3.3V Voltage Regulator
Legend: I = Input, O = Output, P = Power
Note 1: All power supply and ground pins must be connected, including analog supplies (AV
DD) and ground (AVSS).
2: Valid only for PIC18F6XJ5X/8XJ5X families. This pin should be connected to V
DD during programming.
