Memory organization PM0051
6/27 Doc ID 14614 Rev 3
2 Memory organization
This section describes the memory organization corresponding to:
● Access line and performance line STM8S microcontrollers
● Medium and high density STM8A microcontrollers
STM8S microcontrollers offer low density (8 Kbytes), medium density (from 16 to
32 Kbytes) and high density (from 32 to 128 Kbytes) Flash program memory, plus data
EEPROM.
STM8A microcontrollers feature medium density (from 8 to 32 Kbytes) and high density
(from 32 to 128 Kbytes) Flash memory, plus data EEPROM.
The memory organization differs from one STM8 family to another. Refer to Section 2.1,
Section 2.2, Section 2.3, Section 2.4, and Section 2.3 for a description of the memory
organization according to microcontroller family and memory density.
A memory accelerator takes advantage of the parallel 4-byte storage, which corresponds to
a word. The Flash program memory and data EEPROM can be erased and programmed at
byte level, word level or block level. In word programming mode, 4 bytes can be
programmed/erased during the same cycle, while in block programming mode, a whole
block is programmed/erase during the same cycle. Refer to Section 2.1, Section 2.2,
Section 2.3, Section 2.4, and Section 2.3 for information on block size according to the
devices.
2.1 Low density STM8S microcontrollers
The memory array is divided into two areas:
● 8 Kbytes of Flash program memory organized in 128 pages or blocks of 64 bytes each.
The Flash program memory is divided into 2 areas, the user boot code area (UBC),
which size can be configured by option byte, and the main program memory area. The
Flash program memory is mapped in the upper part of the STM8S addressing space
and includes the reset and interrupt vectors.
● 640 bytes of data EEPROM (DATA) organized in 10 pages or blocks of 64 bytes each.
One block (64 bytes) contains the option bytes of which 11 are used to configure the
device hardware features. The options bytes can be programmed in user, IAP and
ICP/SWIM modes.
Refer to Ta ble 1 for a detailed description of the memory partition for low density STM8S
microcontrollers.
