TMP01
Rev. E | Page 4 of 20
V
+
1kΩ
20pF
00333-002
Figure 2. Test Load
TMP01FJ
TO-99 metal can package. V+ = 5 V, GND = 0 V, −40°C ≤ T
A
≤ +85°C, unless otherwise noted.
Table 2.
Parameter Symbol Conditions Min Typ Max Unit
INPUTS SET HIGH, SET LOW
Offset Voltage V
OS
0.25 mV
Offset Voltage Drift TCV
OS
3 μV/°C
Input Bias Current, F Grade I
B
25 100 nA
OUTPUT VPTAT
Output Voltage VPTAT T
A
= 25°C, no load 1.49 V
Scale Factor
1
TCV
PTAT
5 mV/K
Temperature Accuracy, F Grade T
A
= 25°C, no load −3 ±1.0 3 °C
Temperature Accuracy, F Grade 10°C < T
A
< 40°C, no load ±1.5 °C
Temperature Accuracy, F Grade −40°C < T
A
< 85°C, no load −5.0 ±2 5.0 °C
Temperature Accuracy, F Grade ΔVPTAT −55°C < T
A
< 125°C, no load ±2.5 °C
Repeatability Error
2
0.25 Degree
Long-Term Drift Error
3,
4
0.25 0.5 Degree
Power Supply Rejection Ratio PSRR T
A
= 25°C, 4.5 V ≤ V+ ≤ 13.2 V ±0.02 ±0.1 %/V
OUTPUT VREF
Output Voltage, F Grade VREF T
A
= 25°C, no load 2.490 2.500 2.510 V
Output Voltage, F Grade VREF −40°C < T
A
< 85°C, no load 2.485 2.500 2.515 V
Output Voltage, F Grade VREF −55°C < T
A
< 125°C, no load 2.5 ± 0.015 V
Drift TC
VREF
−10 ppm/°C
Line Regulation 4.5 V ≤ V+ ≤ 13.2 V ±0.01 ±0.05 %/V
Load Regulation 10 μA ≤ I
VREF
≤ 500 μA ±0.1 ±0.25 %/mA
Output Current, Zero Hysteresis IV
REF
7 μA
Hysteresis Current Scale Factor
1
SF
HYS
5.0 μA/°C
Turn-On Settling Time To rated accuracy 25 μs
OPEN-COLLECTOR OUTPUTS
OVER
,
UNDER
Output Low Voltage V
OL
I
SINK
= 1.6 mA 0.25 0.4 V
V
OL
I
SINK
= 20 mA 0.6 V
Output Leakage Current I
OH
V+ = 12 V 1 100 μA
Fall Time t
HL
See Figure 2 40 ns
POWER SUPPLY
Supply Range V+ 4.5 13.2 V
Supply Current I
SY
Unloaded, +V = 5 V 400 500 μA
I
SY
Unloaded, +V = 13.2 V 450 800 μA
Power Dissipation P
DISS
+V = 5 V 2.0 2.5 mW
1
K = °C + 273.15.
2
Maximum deviation between 25°C readings after temperature cycling between −55°C and +125°C.
3
Guaranteed but not tested.
4
Observed in a group sample over an accelerated life test of 500 hours at 150°C.
