ABSOLUTE MAXIMUM RATINGS
(1)
TMP300
SBOS335A – JUNE 2005 – REVISED SEPTEMBER 2007
This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could cause the device not to meet its published specifications.
ORDERING INFORMATION
(1)
PRODUCT PACKAGE-LEAD PACKAGE DESIGNATOR PACKAGE MARKING
TMP300 SC70-6 DCK BPN
TMP300 SOT23-6
(2)
DBV T300
(1) For the most current package and ordering information see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com .
(2) Available 4Q, 2007.
VALUE UNIT
Supply Voltage (V+) +18 V
Signal Input Terminals, Voltage
(2)
– 0.5 to (V+) + 0.5 V
Signal Input Terminals, Current
(2)
± 10 mA
Output Short-Circuit (I
SC
)
(3)
Continuous
Open-Drain Output (V+) + 0.5 V
Operating Temperature – 40 to +150 ° C
Storage Temperature – 55 to +150 ° C
Junction Temperature (T
J
) +150 ° C
Human Body Model (HBM) 4000 V
ESD Rating
Charged Device Model (CDM) 1000 V
(1) Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may
degrade device reliability. These are stress ratings only, and functional operation of the device at these or any other conditions beyond
those specified is not supported.
(2) Input terminals are diode-clamped to the power-supply rails. Input signals that can swing more than 0.5V beyond the supply rails should
be current limited to 10mA or less.
(3) Short-circuit to ground.
2 Submit Documentation Feedback Copyright © 2005 – 2007, Texas Instruments Incorporated
Product Folder Link(s): TMP300
