TMP300
www.ti.com
SBOS335D –JUNE 2005–REVISED JANUARY 2016
5 Specifications
5.1 Absolute Maximum Ratings
(1)
MIN MAX UNIT
V+ Supply voltage +18 V
Signal input pins, voltage
(2)
–0.5 (V+) + 0.5 V
Signal input pins, current
(2)
–10 10 mA
I
SC
Output short-circuit
(3)
Continuous
Open-drain output (V+) + 0.5 V
T
A
Functional temperature –40 +150 °C
T
stg
Storage temperature –55 +150 °C
T
J
Junction temperature +150 °C
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) Input pins are diode-clamped to the power-supply rails. Input signals that can swing more than 0.5V beyond the supply rails should be
current limited to 10mA or less.
(3) Short-circuit to ground.
5.2 ESD Ratings
VALUE UNIT
Human-body model (HBM) ±4000
V
(ESD)
Electrostatic discharge V
Charged-device model (CDM) ±1000
Copyright © 2005–2016, Texas Instruments Incorporated Submit Documentation Feedback 3
Product Folder Links: TMP300
