DS187 (v1.19) October 3, 2016 www.xilinx.com
Product Specification 1
© Copyright 2011–2016 Xilinx, Inc. Xilinx, the Xilinx logo, Zynq, Virtex, Artix, Kintex, Spartan, ISE, Vivado and other designated brands included herein are trademarks of Xilinx
in the United States and other countries. AMBA, AMBA Designer, ARM, Cortex-A9, CoreSight, Cortex, PrimeCell, ARM Powered, and ARM Connected Partner are trademarks
of ARM Ltd. All other trademarks are the property of their respective owners.
Introduction
The Zynq®-7000 All Programmable SoCs are available in -3,
-2, -1, and -1LI speed grades, with -3 having the highest
performance. The -1LI devices can operate at either of two
programmable logic (PL) V
CCINT
/V
CCBRAM
voltages, 0.95V
and 1.0V, and are screened for lower maximum static power.
The speed specification of a -1LI device is the same as the -1
speed grade. When operated at PL V
CCINT
/V
CCBRAM
= 0.95V,
the -1LI static and dynamic power is reduced. Zynq-7000
device DC and AC characteristics are specified in
commercial, extended, industrial and expanded (Q-temp)
temperature ranges. Except for the operating temperature
range or unless otherwise noted, all the DC and AC electrical
parameters are the same for a particular speed grade (that
is, the timing characteristics of a -1 speed grade industrial
device are the same as for a -1 speed grade commercial
device). However, only selected speed grades and/or
devices are available in the commercial, extended,
industrial, or Q-temp temperature ranges.
All supply voltage and junction temperature specifications
are representative of worst-case conditions. The parameters
included are common to popular designs and typical
applications.
The available device/package combinations are outlined in:
• Zynq-7000 All Programmable SoC Overview (DS190)
• XA Zynq-7000 All Programmable SoC Overview (DS188
)
• Defense-grade Zynq-7000Q All Programmable SoC
Overview (DS196
)
This Zynq-7000 AP SoC data sheet, which covers the
specifications for the XC7Z007S, XC7Z012S, XC7Z014S,
XC7Z010, XA7Z010, XC7Z015, XC7Z020, XA7Z020, and
XQ7Z020, complements the Zynq-7000 AP SoC
documentation suite available on the Xilinx website at
www.xilinx.com/zynq
.
DC Characteristics
Zynq-7000 All Programmable SoC
(Z-7007S, Z-7012S, Z-7014S, Z-7010, Z-7015, and Z-7020):
DC and AC Switching Characteristics
DS187 (v1.19) October 3, 2016 Product Specification
Table 1: Absolute Maximum Ratings
(1)
Symbol Description Min Max Units
Processing System (PS)
V
CCPINT
PS internal logic supply voltage –0.5 1.1 V
V
CCPAUX
PS auxiliary supply voltage –0.5 2.0 V
V
CCPLL
PS PLL supply –0.5 2.0 V
V
CCO_DDR
PS DDR I/O supply voltage –0.5 2.0 V
V
CCO_MIO
(2)
PS MIO I/O supply voltage –0.5 3.6 V
V
PREF
PS input reference voltage –0.5 2.0 V
V
PIN
(2)(3)(4)(5)
PS MIO I/O input voltage –0.40 V
CCO_MIO
+0.55 V
PS DDR I/O input voltage –0.55 V
CCO_DDR
+0.55 V
Programmable Logic (PL)
V
CCINT
PL internal supply voltage –0.5 1.1 V
V
CCAUX
PL auxiliary supply voltage –0.5 2.0 V
V
CCBRAM
PL supply voltage for the block RAM memories –0.5 1.1 V
V
CCO
PL supply voltage for HR I/O banks –0.5 3.6 V
V
REF
Input reference voltage –0.5 2.0 V
