24AA00/24LC00/24C00
DS21178H-page 4 1996-2011 Microchip Technology Inc.
2.0 PIN DESCRIPTIONS
Pin Function Table
2.1 SDA Serial Data
This is a bidirectional pin used to transfer addresses
and data into and data out of the device. It is an open
drain terminal, therefore the SDA bus requires a pull-up
resistor to V
CC (typical 10 k for 100 kHz, 2 k for
400 kHz).
For normal data transfer SDA is allowed to change only
during SCL low. Changes during SCL high are
reserved for indicating the Start and Stop conditions.
2.2 SCL Serial Clock
This input is used to synchronize the data transfer from
and to the device.
2.3 Noise Protection
The SCL and SDA inputs have Schmitt Trigger and
filter circuits which suppress noise spikes to assure
proper device operation even on a noisy bus.
Name PDIP SOIC TSSOP DFN
(1)
TDFN
(1)
SOT-23 Description
NC 1, 2, 3 1, 2, 3 1, 2, 3 1, 2, 3 1, 2, 3 — Not Connected
V
SS 4 4 4 4 4 2 Ground
SDA 5 5 5 5 5 3 Serial Address/Data I/O
SCL 6 6 6 6 6 1 Serial Clock
WP 7 7 7 7 7 5 Write-Protect Input
V
CC 8 8 8 8 8 4 +1.8V to 5.5V Power Supply
Note 1: The exposed pad on the DFN/TDFN packages can be connected to VSS or left floating.
