Spec-00214 E

Polyester POLYPRO™, TYPe 4X

EQUIPMENT PROTECTION SOLUTIONSSUBJECT TO CHANGE WITHOUT NOTICENoN-Metallic1

Spec-00214

763.422.2211

763.422.2600

NoN-Metal lic

Polyester

PolyPro™, tyPe 4X

iNDUstry staNDarDs

Mounting brackets required to meet UL/CSA external mounting

requirements.

UL 508A Listed; Type 4, 4X, 12, 13; File No. E61997

cUL Listed per CSA C22.2 No 94; Type 4, 4X, 12, 13; File No.

E61997

Enclosure flammability evaluated per UL 508A

Window flammability evaluated per UL 508A

NEMA/EEMAC Type 4, 4X, 12, 13

CSA File No. 42186; Type 4, 4X, 12, 13 (solid covers only)

IEC 60529, IP66

aPPlicatioN

POLYPRO™ polyester enclosures perform exceptionally well

in applications where harsh chemicals, weather extremes and

corrosive environments demand toughness from a lightweight

enclosure. Providing excellent ultraviolet protection and a tight

environmental seal, these versatile, feature-rich enclosures are

also recyclable.

sPeciFicatioNs

• Non-glass-filled polyester material offers superior UV

resistance; eliminates fiberbloom associated with fiberglass

• Provides excellent chemical resistance to a broad range of

solvents, alkalis and acids

• Resists cracking and provides excellent impact resistance

• Lighter-weight than fiberglass

• Recyclable

• Easy, dustless in-field modifications using standard tools

• Overlapping tongue-and-groove raised cover and gasket provide

a secure Type 4X seal

•

Removable snap-hinge cover allows for easy access to cover and

body for modifications

• Molded layout grid on inside of body and solid covers assists with

component mounting

• Molded-in embosses for rear panel mounting

• Optional cover screws included with all models

• Internal rail system and adjustable panel blocks allow for panel

height adjustment and installation of multiple panels

• Scratch-resistant polycarbonate windows

• Standard models include body and cover, two mounting feet,

two latch assemblies with optional cover screws and hardware

(adjustable panel blocks and panels sold separately)

FiNisH

RAL 7035 light-gray textured finish inside and out

accessories
