Spec-00214 E
Polyester POLYPRO™, TYPe 4X
PH 763.422.2211 • FAX 763.422.2600 • HOFFMANONLINE.COMEQUIPMENT PROTECTION SOLUTIONS NoN-Metallic 2
Standard Product
Catalog Number
AxBxC in./mm
Cover
Type
Steel
Panel
Aluminum
Panel
Panel Size
D x E
in./mm
F
in./mm
G
in./mm
H
in./mm
J
in./mm
L
in./mm
M
in./mm
N
in./mm
W
in./mm
A644PHC 6.12 x 4.12 x 4.38
155 x 105 x 111
Solid A6P4 A6P4AL 4.88 x 2.88
124 x 73
4.32
110
7.38
187
2.56
65
3.91
99
8.15
207
—
—
—
—
5.23
133
A644PHCW 6.12 x 4.12 x 4.38
155 x 105 x 111
Window A6P4 A6P4AL 4.88 x 2.88
124 x 73
4.32
110
7.38
187
2.56
65
3.91
99
8.15
207
4.25
108
2.25
57
5.23
133
A664PHC 6.12 x 6.12 x 4.38
155 x 155 x 111
Solid A6P6 A6P6AL 4.88 x 4.88
124 x 124
4.32
110
7.38
187
4.56
116
3.91
99
8.15
207
—
—
—
—
7.23
184
A664PHCW 6.12 x 6.12 x 4.38
155 x 155 x 111
Window A6P6 A6P6AL 4.88 x 4.88
124 x 124
4.32
110
7.38
187
4.56
116
3.91
99
8.15
207
4.25
108
4.25
108
7.23
184
A864PHC 8.12 x 6.12 x 4.38
206 x 155 x 111
Solid A8P6 A8P6AL 6.75 x 4.88
171 x 124
4.32
110
9.38
238
4.56
116
3.91
99
10.15
258
—
—
—
—
7.23
184
A864PHCW 8.12 x 6.12 x 4.38
206 x 155 x 111
Window A8P6 A8P6AL 6.75 x 4.88
171 x 124
4.32
110
9.38
238
4.56
116
3.91
99
10.15
258
6.25
159
4.25
108
7.23
184
A884PHC 8.12 x 8.12 x 4.38
206 x 206 x 111
Solid A8P8 A8P8AL 6.75 x 6.88
171 x 175
4.32
110
9.38
238
6.56
167
3.91
99
10.15
258
—
—
—
—
9.23
234
A884PHCW 8.12 x 8.12 x 4.38
206 x 206 x 111
Window A8P8 A8P8AL 6.75 x 6.88
171 x 175
4.32
110
9.38
238
6.56
167
3.91
99
10.15
258
6.25
159
6.25
159
9.23
234
A1084PHC 10.12 x 8.12 x 4.38
257 x 155 x 111
Solid A10P8 A10P8AL 8.75 x 6.88
222 x 175
4.32
110
11.38
289
6.56
167
3.91
99
12.15
309
—
—
—
—
9.23
234
A1084PHCW 10.12 x 8.12 x 4.38
257 x 155 x 111
Window A10P8 A10P8AL 8.75 x 6.88
222 x 175
4.32
110
11.38
289
6.56
167
3.91
99
12.15
309
8.25
210
6.25
159
9.23
234
A10106PHC 10.04 x 10.04 x 6.38
255 x 255 x 162
Solid A10P10 A10P10AL 8.75 x 8.88
222 x 226
6.32
161
11.31
287
8.56
217
5.91
150
12.08
307
—
—
—
—
11.23
285
A10106PHCW 10.04 x 10.04 x 6.38
255 x 255 x 162
Window A10P10 A10P10AL 8.75 x 8.88
222 x 226
6.32
161
11.31
287
8.56
217
5.91
150
12.08
307
8.25
210
8.25
210
11.23
285
A12106PHC 12.08 x 10.09 x 6.38
307 x 256 x 162
Solid A12P10 A12P10AL 10.75 x 8.88
273 x 226
6.32
161
13.34
339
8.56
217
5.91
150
14.08
358
—
—
—
—
11.23
285
A12106PHCW 12.08 x 10.09 x 6.38
307 x 256 x 162
Window A12P10 A12P10AL 10.75 x 8.88
273 x 226
6.32
161
13.34
339
8.56
217
5.91
150
14.08
358
10.25
260
8.25
210
11.23
285
A14128PHC 14.02 x 12.01 x 8.35
356 x 305 x 212
Solid A14P12 A14P12AL 12.75 x 10.88
324 x 276
8.27
210
15.27
388
10.56
268
7.91
201
16.04
407
—
—
—
—
13.32
338
A14128PHCW 14.02 x 12.01 x 8.35
356 x 305 x 212
Window A14P12 A14P12AL 12.75 x 10.88
324 x 276
8.27
210
15.27
388
10.56
268
7.91
201
16.04
407
12.25
311
10.25
260
13.32
338
A16148PHC 16.02 x 14.01 x 8.35
407 x 356 x 212
Solid A16P14 A16P14AL 14.75 x 12.88
375 x 327
8.27
210
17.27
439
12.56
319
7.91
201
18.04
458
—
—
—
—
15.32
389
A16148PHCW 16.02 x 14.01 x 8.35
407 x 356 x 212
Window A16P14 A16P14AL 14.75 x 12.88
375 x 327
8.27
210
17.27
439
12.56
319
7.91
201
18.04
458
14.25
362
12.25
311
15.32
389
A181610PHC 17.95 x 15.94 x 10.35
456 x 405 x 263
Solid A18P16 A18P16AL 16.75 x 14.88
425 x 378
10.27
261
19.20
488
14.56
370
9.91
252
19.97
507
—
—
—
—
17.32
440
A181610PHCW 17.95 x 15.94 x 10.35
456 x 405 x 263
Window A18P16 A18P16AL 16.75 x 14.88
425 x 378
10.27
261
19.20
488
14.56
370
9.91
252
19.97
507
16.25
413
14.25
362
17.32
440
Purchase panels separately. Panels are available in aluminum, mild steel, stainless steel, conductive and composite materials.
