若手册格式错乱，请下载阅览PDF原文件
www.vishay.com For technical questions, contact: CDC@vishay.com
Document Number: 28511
30 Revision: 07-Jan-10
D Series
Vishay BCcomponents
Ceramic Disc Capacitors
Class 1 and 2, 100 V
DC
, General Purpose
ORDERING INFORMATION, CLASS 2, 100 V
DC
, KINKED AND STRAIGHT
C
(pF)
TOL.
(%)
D
MAX.
(mm)
LEAD SPACING
F
(mm)
SH/DR
MAX.
(1)
(mm)
CLEAR TEXT CODE
13
TH
DIGIT:
T = REEL; U = AMMO; 3 = BULK
CLASS 2 Y5P
150
±10
5.0
5.0 4.0 D151K20Y5PH6.J5R
2.5 1.5 D151K20Y5PH6.L2R
180
5.0 4.0 D181K20Y5PH6.J5R
2.5 1.5 D181K20Y5PH6.L2R
220
5.0 4.0 D221K20Y5PH6.J5R
2.5 1.5 D221K20Y5PH6.L2R
330
5.0 4.0 D331K20Y5PH6.J5R
2.5 1.5 D331K20Y5PH6.L2R
470
5.0 4.0 D471K20Y5PH6.J5R
2.5 1.5 D471K20Y5PH6.L2R
680
5.0 4.0 D681K20Y5PH6.J5R
2.5 1.5 D681K20Y5PH6.L2R
1000
5.0 4.0 D102K20Y5PH6.J5R
2.5 1.5 D102K20Y5PH6.L2R
1500
6.5
5.0 4.0 D152K25Y5PH6.J5R
2.5 1.5 D152K25Y5PH6.L2R
1800
5.0 4.0 D182K25Y5PH6.J5R
2.5 1.5 D182K25Y5PH6.L2R
2200
5.0 4.0 D222K25Y5PH6.J5R
2.5 1.5 D222K25Y5PH6.L2R
3300 7.5
5.0 4.0 D332K29Y5PH6.J5R
2.5 1.5 D332K29Y5PH6.L2R
4700 8.5
5.0 4.0 D472K33Y5PH6.J5R
2.5 1.5 D472K33Y5PH6.L2R
6800 10.0
5.0 4.0 D682K39Y5PH6.J5R
2.5 1.5 D682K39Y5PH6.L2R
10000 11.0
5.0 4.0 D103K43Y5PH6.J5R
2.5 1.5 D103K43Y5PH6.L2R
CLASS 2 Z5U
1000
± 20
5.0
5.0 4.0 D102M20Z5UH6.J5R
2.5 1.5 D102M20Z5UH6.L2R
1500
5.0 4.0 D152M20Z5UH6.J5R
2.5 1.5 D152M20Z5UH6.L2R
2200
5.0 4.0 D222M20Z5UH6.J5R
2.5 1.5 D222M20Z5UH6.L2R
3300
5.0 4.0 D332M20Z5UH6.J5R
2.5 1.5 D332M20Z5UH6.L2R
4700
6.5
5.0 4.0 D472M25Z5UH6.J5R
2.5 1.5 D472M25Z5UH6.L2R
6800
5.0 4.0 D682M25Z5UH6.J5R
2.5 1.5 D682M25Z5UH6.L2R
10 000 7.5
5.0 4.0 D103M29Z5UH6.J5R
2.5 1.5 D103M29Z5UH6.L2R
15 000 8.5
5.0 4.0 D153M33Z5UH6.J5R
2.5 1.5 D153M33Z5UH6.L2R
22 000 10.0
5.0 4.0 D223M39Z5UH6.J5R
2.5 1.5 D223M39Z5UH6.L2R
Note
(1)
SH = seated height; DR = run down
• Maximum thickness 4.0 mm
• Lead style codes refer to lead cofiguration
