Document Number: 28511 For technical questions, contact: CDC@vishay.com
www.vishay.com
Revision: 07-Jan-10 31
D Series
Ceramic Disc Capacitors
Class 1 and 2, 100 V
DC
, General Purpose
Vishay BCcomponents
Note
• The capacitors are supplied in bulk packaging (cardboard boxes), in tape on reel or in ammopack
C
(pF)
TOL.
(%)
D
MAX.
(mm)
LEAD SPACING
F
(mm)
SH/DR
MAX.
(1)
(mm)
CLEAR TEXT CODE
13
TH
DIGIT:
T = REEL; U = AMMO; 3 = BULK
CLASS 2 Y5V
1000
+ 80/- 20
5.0
5.0 4.0 D102Z20Y5VH6.J5R
2.5 1.5 D102Z20Y5VH6.L2R
1500
5.0 4.0 D152Z20Y5VH6.J5R
2.5 1.5 D152Z20Y5VH6.L2R
2200
5.0 4.0 D222Z20Y5VH6.J5R
2.5 1.5 D222Z20Y5VH6.L2R
3300
5.0 4.0 D332Z20Y5VH6.J5R
2.5 1.5 D332Z20Y5VH6.L2R
4700
6.5
5.0 4.0 D472Z25Y5VH6.J5R
2.5 1.5 D472Z25Y5VH6.L2R
6800
5.0 4.0 D682Z25Y5VH6.J5R
2.5 1.5 D682Z25Y5VH6.L2R
10 000 7.5
5.0 4.0 D103Z29Y5VH6.J5R
2.5 1.5 D103Z29Y5VH6.L2R
15 000 8.5
5.0 4.0 D153Z33Y5VH6.J5R
2.5 1.5 D153Z33Y5VH6.L2R
22 000 10.0
5.0 4.0 D223Z39Y5VH6.J5R
2.5 1.5 D223Z39Y5VH6.L2R
CLASS 2 Z5V
4700
+ 80/- 20
5.0
5.0 4.0 D472Z20Z5VH6.J5R
2.5 1.5 D472Z20Z5VH6.L2R
10 000 6.5
5.0 4.0 D103Z25Z5VH6.J5R
2.5 1.5 D103Z25Z5VH6.L2R
22 000 8.5
5.0 4.0 D223Z33Z5VH6.J5R
2.5 1.5 D223Z33Z5VH6.L2R
47 000 11.0
5.0 4.0 D473Z43Z5VH6.J5R
2.5 1.5 D473Z43Z5VH6.L2R
Note
(1)
SH = seated height; DR = run down
• Maximum thickness 4.0 mm
• Lead style codes refer to lead cofiguration
ORDERING INFORMATION, CLASS 2, 100 V
DC
, KINKED AND STRAIGHT
PACKAGING
D
MAX.
(mm)
SIZE CODE
PACKAGING QUANTITIES
BULK REEL AMMO
5.0 (0.20") 20
1000 2500 2000
6.5 (0.25") 25
7.5 (0.29") 29
8.5 (0.33") 33
10.0 (0.39") 39
11.0 (0.43") 43
