PWM
nSLEEP
nFAULT
2.7 to 10.8 V
Controller
M
+ t
+ t
DRV8833C
Stepper or
Brushed DC
Motor Driver
0.7 A
0.7 A
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
DRV8833C
SLVSCP9 –AUGUST 2014
DRV8833C Dual H-Bridge Motor Driver
1 Features 2 Applications
1
• Dual H-Bridge Motor Driver With Current Control
• Point-of-Sale Printers
• Video Security Cameras
– 1 or 2 DC Motors or 1 Stepper Motor
• Office Automation Machines
– Low On-Resistance: HS + LS = 1735 mΩ
(Typical, 25°C)
• Gaming Machines
• Output Current Capability (at V
M
= 5 V, 25°C)
• Robotics
– PWP (HTSSOP) Package
• Battery-Powered Toys
– 0.7-A RMS, 1-A Peak per H-Bridge
3 Description
– 1.4-A RMS in Parallel Mode
The DRV8833C provides a dual-bridge motor driver
– RTE (QFN) Package
solution for toys, printers, and other mechatronic
– 0.6-A RMS, 1-A Peak per H-Bridge
applications.
– 1.2-A RMS in Parallel Mode
The device has two H-bridges and can drive two DC
• Wide Power Supply Voltage Range
brushed motors, a bipolar stepper motor, solenoids,
or other inductive loads.
– 2.7 to 10.8 V
• Integrated Current Regulation
Each H-bridge output consists of a pair of N-channel
and P-channel MOSFETs, with circuitry that regulates
• Easy Pulse-Width-Modulation (PWM) Interface
the winding current. With proper PCB design, each H-
• 1.6-µA Low-Current Sleep Mode (at 5 V)
bridge of the DRV8833C can drive up to 700-mA
• Small Package and Footprint
RMS (or DC) continuously, at 25°C with a V
M
supply
of 5 V. The device can support peak currents of up to
– 16 HTSSOP (PowerPAD™) 5.00 × 6.40 mm
1 A per bridge. Current capability is reduced slightly
– 16 QFN (PowerPAD) 3.00 × 3.00 mm
at lower V
M
voltages.
• Protection Features
Internal shutdown functions with a fault output pin are
– V
M
Undervoltage Lockout (UVLO)
provided for overcurrent protection, short-circuit
– Overcurrent Protection (OCP)
protection, UVLO, and overtemperature. A low-power
sleep mode is also provided.
– Thermal Shutdown (TSD)
– Fault Indication Pin (nFAULT)
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE (NOM)
HTSSOP (16) 5.00 mm × 6.40 mm
DRV8833C
QFN (16) 3.00 mm × 3.00 mm
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
