© 2007 Microchip Technology Inc. DS21314G-page 11
MCP601/1R/2/3/4
3.0 PIN DESCRIPTIONS
Descriptions of the pins are listed in Table 3-1 (single op amps) and Table 3-2 (dual and quad op amps).
TABLE 3-1: PIN FUNCTION TABLE FOR SINGLE OP AMPS
TABLE 3-2: PIN FUNCTION TABLE FOR DUAL AND QUAD OP AMPS
3.1 Analog Outputs
The op amp output pins are low-impedance voltage
sources.
3.2 Analog Inputs
The op amp non-inverting and inverting inputs are high-
impedance CMOS inputs with low bias currents.
3.3 Chip Select Digital Input
This is a CMOS, Schmitt-triggered input that places the
part into a low power mode of operation.
3.4 Power Supply Pins
The positive power supply pin (V
DD
) is 2.5V to 6.0V
higher than the negative power supply pin (V
SS
). For
normal operation, the other pins are at voltages
between V
SS
and V
DD
.
Typically, these parts are used in a single (positive)
supply configuration. In this case, V
SS
is connected to
ground and V
DD
is connected to the supply. V
DD
will
need bypass capacitors.
MCP601 MCP601R MCP603
Symbol Description
PDIP, SOIC,
TSSOP
SOT-23-5
SOT-23-5
(Note 1)
SOT-23-6
PDIP, SOIC,
TSSOP
6116 6 V
OUT
Analog Output
2442 2 V
IN
– Inverting Input
3333 3 V
IN
+ Non-inverting Input
7527 7 V
DD
Positive Power Supply
4254 4 V
SS
Negative Power Supply
———8 8 CSChip Select
1, 5, 8 — — 1, 5 1 NC No Internal Connection
Note 1: The MCP601R is only available in the 5-pin SOT-23 package.
MCP602 MCP604
Symbol Description
PDIP, SOIC,
TSSOP
PDIP, SOIC,
TSSOP
11 V
OUTA
Analog Output (op amp A)
22 V
INA
– Inverting Input (op amp A)
33 V
INA
+ Non-inverting Input (op amp A)
84 V
DD
Positive Power Supply
55 V
INB
+ Non-inverting Input (op amp B)
66 V
INB
– Inverting Input (op amp B)
77 V
OUTB
Analog Output (op amp B)
—8 V
OUTC
Analog Output (op amp C)
—9 V
INC
– Inverting Input (op amp C)
—10 V
INC
+ Non-inverting Input (op amp C)
411 V
SS
Negative Power Supply
—12 V
IND
+ Non-inverting Input (op amp D)
—13 V
IND
– Inverting Input (op amp D)
—14 V
OUTD
Analog Output (op amp D)
