© 2005 Microchip Technology Inc. DS21981A-page 1
MCP2030
Device Features:
• Three input pins for analog input signals
• High input detection sensitivity (3 mV
PP
, typical)
• High modulation depth sensitivity (as low as 8%)
• Three output selections:
- Demodulated data
- Carrier clock
- RSSI
• Input carrier frequency: 125 kHz, typical
• Input data rate: 10 Kbps, maximum
• 8 internal Configuration registers
• Bidirectional transponder communication
(LF talk back)
• Programmable antenna tuning capacitance
(up to 63 pF, 1 pF/step)
• Programmable output enable filter
• Low standby current: 4 μA (with 3 channels
enabled), typical
• Low operating current: 13 μA (with 3 channels
enabled), typical
• Serial Peripheral Interface (SPI™) with external
devices
• Supports Battery Back-Up mode and batteryless
operation with external circuits
• Industrial and Extended Temperature Range:
-40°C to +85°C (industrial)
Typical Applications:
• Automotive industry applications:
- Passive Keyless Entry (PKE) transponder
- Remote door locks and gate openers
- Engine immobilizer
- LF initiator sensor for tire pressure monitoring
systems
• Security Industry applications:
- Long range access control transponder
