RT9011
1
DS9011-08 April 2011 www.richtek.com
Ordering Information
General Description
The RT9011 is a dual channel, low noise, and low dropout
regulator sourcing up to 300mA at each channel. The range
of output voltage is from 1.2V to 3.6V by operating from
2.5V to 5.5V input.
The RT9011 offers 2% accuracy, extremely low dropout
voltage (240mV @ 300mA), and extremely low ground
current, only 27μA per LDO. The shutdown current is near
zero current which is suitable for battery-power devices.
Other features include current limiting, over temperature,
output short circuit protection.
The RT9011 is short circuit thermal folded back protected.
The IC lowers its OTP trip point from 165°C to 110°C when
output short circuit occurs (VOUT < 0.4V) providing
maximum safety to end users.
The RT9011 can operate stably with very small ceramic
output capacitors, reducing required board space and
component cost. The RT9011 is available in fixed output
voltages in the TSOT-23-6, WDFN-8L 2x2, WDFN-10L 3x3,
WDFN-8L 3x3 and WDFN-6L 1.6x1.6 packages.
Portable Power Management 300mA Dual LDO Regulator
Features
z Wide Operating Voltage Ranges : 2.5V to 5.5V
z Low-Noise for RF Application
z No Noise Bypass Capacitor Required
z Fast Response in Line/Load Transient
z TTL-Logic-Controlled Shutdown Input
z Low Temperature Coefficient
zz
zz
z Dual LDO Outputs (300mA/300mA)
zz
zz
z Ultra-low Quiescent Current 27
μμ
μμ
μA/LDO
zz
zz
z High Output Accuracy 2%
zz
zz
z Short Circuit Protection
zz
zz
z Thermal Shutdown Protection
zz
zz
z Current Limit Protection
zz
zz
z Short Circuit Thermal Folded Back Protection
zz
zz
z Tiny TSOT-23-6 and 6-Lead/8-Lead/10-Lead WDFN
Packages
zz
zz
z RoHS Compliant and 100% Lead (Pb)-Free
Applications
zz
zz
z CDMA/GSM Cellular Handsets
zz
zz
z Battery-Powered Equipment
zz
zz
z Laptop, Palmtops, Notebook Computers
zz
zz
z Hand-Held Instruments
zz
zz
z PCMCIA Cards
zz
zz
z Portable Information Appliances
Marking Information
For marking information, contact our sales representative
directly or through a Richtek distributor located in your
area.
Code Voltage Code Voltage Code Voltage
A 3.5 B 1.3 C 1.2
D 1.85 E 2.1 F 1.5
G 1.8 H 2 J 2.5
K 2.6 L 2.7 M 2.8
N 2.85 P 3 Q 3.1
R 3.2 S 3.3 T 2.65
V 2.9 W 1.6 X 3.15
Y 1.9
Available Voltage Version
Note :
Richtek products are :
` RoHS compliant and compatible with the current require-
ments of IPC/JEDEC J-STD-020.
` Suitable for use in SnPb or Pb-free soldering processes.
RT9011-
Package Type
J6 : TSOT-23-6
QW : WDFN-8L 2x2 (W-Type)
QWA : WDFN-10L 3x3 (W-Type)
QWB : WDFN-8L 3x3 (W-Type)
QWC : WDFN-6L 1.6x1.6 (W-Type)
Lead Plating System
P : Pb Free
G : Green (Halogen Free and Pb Free)
Output Voltage : VOUT1/VOUT2
VOUT2 > VOUT1 is Recommended
