Package information STM32F091xB STM32F091xC
102/127 DocID026284 Rev 3
Device marking
The following figure gives an example of topside marking orientation versus pin 1 identifier
location.
Figure 35. UFBGA100 package marking example
1. Parts marked as "ES", "E" or accompanied by an Engineering Sample notification letter, are not yet
qualified and therefore not yet ready to be used in production and any consequences deriving from such
usage will not be at ST charge. In no event, ST will be liable for any customer usage of these engineering
samples in production. ST Quality has to be contacted prior to any decision to use these Engineering
Samples to run qualification activity.
069
5HYLVLRQFRGH
:88
45.'
7$)
3
'DWHFRGH
3URGXFWLGHQWLILFDWLRQ
3LQLGHQWLILHU
