Advantage Supporting Feature
Lowest system cost
• Requires only two core voltages to operate
• Available in low-cost wirebond packaging
• Includes innovative features such as Configuration via Protocol
(CvP) and partial reconfiguration
Summary of Cyclone V Features
Table 2: Summary of Features for Cyclone V Devices
Feature Description
Technology • TSMC's 28-nm low-power (28LP) process technology
• 1.1 V core voltage
Packaging • Wirebond low-halogen packages
• Multiple device densities with compatible package footprints for seamless
migration between different device densities
• RoHS-compliant and leaded
(1)
options
High-performance FPGA
fabric
Enhanced 8-input ALM with four registers
Internal memory blocks • M10K—10-kilobits (Kb) memory blocks with soft error correction code
(ECC)
• Memory logic array block (MLAB)—640-bit distributed LUTRAM where
you can use up to 25% of the ALMs as MLAB memory
Embedded Hard IP blocks
Variable-precision
DSP
• Native support for up to three signal processing
precision levels (three 9 x 9, two 18 x 18, or one
27 x 27 multiplier) in the same variable-precision DSP
block
• 64-bit accumulator and cascade
• Embedded internal coefficient memory
• Preadder/subtractor for improved efficiency
Memory controller DDR3, DDR2, and LPDDR2 with 16 and 32 bit ECC
support
Embedded
transceiver I/O
PCI Express
®
(PCIe
®
) Gen2 and Gen1 (x1, x2, or x4)
hard IP with multifunction support, endpoint, and root
port
(1)
Contact Altera for availability.
2
Summary of Cyclone V Features
CV-51001
2014.10.06
Altera Corporation
Cyclone V Device Overview
Send Feedback
