2
[Ie] rated operational current 0.11 A at 250 V DC, R300 conforming to NEMA
1.2 A at 600 V AC, A600 conforming to NEMA
[Ithe] conventional enclosed thermal current 10 A
[Ui] rated insulation voltage 600 V degree of pollution 3 conforming to CSA C22.2 No 14 for contact block
600 V degree of pollution 3 conforming to UL 508 for contact block
[Uimp] rated impulse withstand voltage 2.64 kV AC for 1 s conforming to CSA
2.2 kV AC for 1 min conforming to UL
2.5 kV AC for 1 min conforming to CE
Short circuit protection 10 A by CC fuse, protection type: non-time delay
Electrical durability 1000000 cycles
Local signalling Without
Mechanical durability 10000000 cycles
Width 1.55 in
Height 4.02 in
Depth 2.5 in
Product weight 1.25 lb(US)
Environment
Shock resistance 60 gn (duration = 9 ms) conforming to IEC 60068-2-27
Vibration resistance 25 gn (f = 10...150 Hz) conforming to IEC 60068-2-6
NEMA degree of protection NEMA 13 conforming to Nema type 250
NEMA 12 conforming to Nema type 250
NEMA 6P conforming to Nema type 250
NEMA 6 conforming to Nema type 250
NEMA 4 conforming to Nema type 250
NEMA 2 conforming to Nema type 250
NEMA 1 conforming to Nema type 250
IP degree of protection IP67 conforming to IEC 60529
Class of protection against electric shock Class 0 conforming to IEC 61140
Ambient air temperature for operation -20...185 °F for standard environment
Ambient air temperature for storage -20...185 °F
Environmental characteristic Standard environment
Protective treatment Epoxy powder coat
Ordering and shipping details
Category 21499 - 9007 C LIMIT SWITCHES
Discount Schedule DS1
GTIN 00785901812081
Nbr. of units in pkg. 10
Package weight(Lbs) 1.25
Product availability Stock - Normally stocked in distribution facility
Returnability Y
Country of origin MX
Offer Sustainability
Sustainable offer status Green Premium product
RoHS
Compliant - since 1150 - Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Product environmental profile
Available Download Product Environmental
Product end of life instructions Need no specific recycling operations
Contractual warranty
Period 18 months
