AD8045ACPZ-R2 产品封装文件 - ADI（亚德诺）
制造商:
ADI（亚德诺）
分类:
运算放大器
封装:
LFCSP-8
描述:
3内华达州/ Hz的超低失真，高速运算放大器 3 nV/Hz Ultralow Distortion, High Speed Op Amp
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
封装信息在P1P2P3P4P5P6P7
导航目录
AD8045ACPZ-R2数据手册
Page:
of 7 Go
若手册格式错乱，请下载阅览PDF原文件
2
Tape and Reel Packaging Visit analog.com
3
Table 1. Standard Package Tape and Reel
(
See Page 7 for Reel Denitions
)
Device Package Type
Package
Designator
Body Size
(
mm
)
Number
of Leads
Reel Quantity
Tape Width
(
mm
)
Tape Pitch
(
mm
)
Pin 1
Orientation
7" Reel 13" Reel
(
4" Hub
)
13" Reel
(
6" Hub
)
PLCC P N/A 20 250 1000 N/A 16 12 M1
PLCC P N/A 28, 32 Not offered 750 N/A 24 16 M1
PLCC P N/A 44 Not offered 500 N/A 32 24 M1
PLCC P N/A 68 Not offered N/A 250 44 32 M1
PLCC P N/A 84 Not offered N/A 250 44 36 M1
JLCC J N/A 28 Not offered 250 N/A 24 16 M1
JLCC J N/A 44 Not offered 500 N/A 32 24 M1
LCC E N/A 8 250 3000 N/A 12 8 M1
LCC E N/A 14 500 2000 N/A 16 12 C2
LCC_V EY 9 × 9 All counts Not offered 500 N/A 24 12 C4
SOIC_N/SOIC_N_EP R/RD N/A 8 1000 2500 N/A 12 8 C1
SOIC_N/SOIC_N_EP R/RD N/A 14, 16 1000 2500 N/A 16 8 C1
QSOP RQ/RC N/A 16 1000 2500 N/A 12 8 C1
QSOP RQ N/A 20, 24, 28 1000 2500 N/A 16 8 C1
SOIC_W_FP RN N/A 28 400 1000 N/A 16 12 C1
SOIC_W/SOIC_W_BAT RW/RB N/A 14, 16 400 1000 N/A 16 12 C1
SOIC_W/SOIC_W_BAT RW/RB N/A 18 400 1000 N/A 24 16 C1
SOIC_W/SOIC_W_BAT RW/RB N/A 20, 24 400 1000 N/A 24 12 C1
SOIC_W/SOIC_W_BAT RW/RB N/A 28 400 1000 N/A 32 12 C1
SOIC_CAV RG N/A 16 Not offered 500 N/A 24 16 C1
SOIC_IC RI N/A 6 400 1500 N/A 16 12 C1
SOIC_IC RI N/A 8 400 1500 N/A 16 12 C1
SOIC_IC RI N/A 16 400 1000 N/A 24 12 C1
SOIC_IC RI N/A 20 400 1000 N/A 24 12 C1
SSOP RS N/A 16, 20, 24 500 1500 N/A 16 12 C1
SSOP RS N/A 28 500 1500 N/A 24 12 C1
PSOP2 RP N/A 20, 28 200 1000 N/A 24 12 C1
PSOP3 RR N/A 20 Not offered 750 N/A 24 20 C1
SOT-23-3 RT N/A 3 3000 10,000 N/A 8 4 C4
SOT-23
1
RJ/RT N/A 5, 6, 8 3000 10,000 N/A 8 4 C4
SOT-66 RY N/A 5, 6 3000 N/A N/A 8 4 C4
SOT-143 RA N/A 4 3000 10,000 N/A 8 4 C4
TSOT UJ N/A 5, 6, 8 3000 10,000 N/A 8 4 C4
SOT-223 KC N/A 3 500 2500 N/A 16 12 C4
SC70 KS
N/A 3, 4, 5, 6 3000 10,000 N/A 8 4 C4
SOT-89 RK N/A 3 1000 3000 N/A 12 8 C1
TSSOP_4.4 RU/RE N/A
8, 14, 16, 20,
24, 28, 38
1000 2500 N/A 16 8 C1
TSSOP_6.1 RV N/A 28, 48 Not offered 2500 N/A 24 12 C1
MSOP/MINI_SO RM/RH N/A 8, 10 1000 3000 N/A 12 8 C1
CERPAK QC N/A 14 Not offered 750 N/A 24 16 C1
TQFP SU/SV 7 × 7 × 1.0 All counts 500 2000 Not offered 16 12 C2
TQFP SU/SV 10 × 10 × 1.0 All counts Not offered 1500 Not offered 24 16 C2
TQFP SU/SV
12 × 12 × 1.0
All counts Not offered 1000 Not offered 24 24 C2
